2. Install the clutch shaft pilot bearing using the J 33842 . See Special Tools. 3. Install the clutch shaft to the differential carrier assembly. 4. Install the inner axle shaft and housing assembly. Refer to Front Drive Axle Inner Shaft and Inner Shaft Housing Replacement (8.25 F4WD Axle) or Front Drive Axle Inner FRONT DRIVE AXLE INNER SHAFT SEAL AND INNER SHAFT BEARING REPLA Tools Required J 8092 Universal Driver Handle - 3/4 in - 10 J 2619-01 Slide Hammer J 29369-1 Bushing and Bearing Remover. See Special Tools. J 29369-2 Bushing and Bearing Remover (2-3 inch). See Special Tools. J 36609 Axle Tube Bearing Installer. See Special Tools. J 45225 Axle Seal Installer. See Special Tools. Removal Procedure 1. Raise the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Drain the differential carrier assembly. Refer to Front Axle Lubricant Replacement. 3. Remove the right side seal and/or bearing by performing the following steps: 1. Remove the inner axle shaft and housing assembly from the differential carrier case assembly. Refer to Front Drive Axle Inner Shaft and Inner Shaft Housing 2. Remove the clutch fork assembly components and the inner axle shaft from the inner axle shaft housing. Refer to Front Drive Axle Inner Shaft and Inner Shaft 3. Install the inner axle shaft housing into a vise. Clamp only on the mounting flange of the inner axle shaft housing. 4. Install the J 29369-1 , 8. See Special Tools.25 inch axle, or the J 29369-2 , 9. See Special Tools.25 inch axle, behind the inner axle shaft seal or the inner axle shaft
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
