Fig. 73: Inner Axle Shaft Housing & Clutch Fork Assembly - Front Drive Axle 1. Remove the inner axle shaft and housing assembly. Refer to Front Drive Axle Inner Shaft and Inner Shaft Housing Replacement (8.25 F4WD Axle) or Front Drive Axle Inner 2. Remove the clutch fork assembly (2) from the inner axle shaft housing (1). 3. Remove the clutch fork inner spring from the differential carrier case assembly, if necessary. Installation Procedure
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
