Fig. 4: Wheel Drive Shaft & Hub 7. Remove the 6 bolts (1) securing the wheel drive shaft inboard flange to the output shaft flange. 8. Remove the drift from the rotor. 9. Remove the stabilizer shaft link from the lower control arm. Refer to Stabilizer Shaft Replacement (2500, 3500) or Stabilizer Shaft Replacement (1500) . 10. Wrap shop towels around both the inner and the outer wheel drive shaft boots in order to avoid damage to the boots during removal and installation. 11. Pull the wheel drive shaft through the lower control arm opening. Installation Procedure
2008 Chevrolet Silverado 1500 2008 DRIVELINE/AXLE Wheel Drive Shafts - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
