DRIVER SUPPORT
}}
}}
335
Camera and radar sensor's field of vision
The camera and radar sensor have limited fields
of vision. In some situations they may detect a
vehicle, large animal, pedestrian or cyclist later
than expected or not detect them at all.
Other vehicles that are dirty may be detected
later than others and in dark conditions, motorcy-
cles may be detected late or not at all.
If a text message is displayed in the instrument
panel indicates that the camera or radar sensor
are blocked, it may be difficult for City Safety to
detect a vehicle, pedestrian or cyclist and the
system's functionality may be reduced.
WARNING
Text messages may not be displayed in all sit-
uations in which the camera and/or radar
sensor are blocked. It is therefore essential to
keep the windshield in front the camera/radar
sensor clean and free from snow, ice, etc.
Camera and radar sensor components should
only be serviced or replaced by a trained and
qualified Volvo service technician.
Action by the driver
Backing up
City Safety is temporarily deactivated while the
vehicle is backing up.
Low speed
City Safety is not activated at very low speeds
(under approx. 3 mph (4 km/h). This means that
the system will not be triggered if your vehicle
approaches a vehicle ahead at very low speed,
such as when parking.
Active driver
Action by the driver always has priority. For this
reason, City Safety may not react or react later
than expected in situations in which the driver is
actively operating the vehicle, even if a collision is
imminent. This is also done to help eliminate
excessive warnings.
Other limitations
City Safety uses the vehicle's camera and radar
sensor, which have certain general limitations.
See the articles "Camera limitations" and "Radar
sensor limitations" for additional information.
WARNING
•
Warnings and braking may be delayed or
not occur at all if traffic, weather or other
conditions prevent the camera and/or
radar sensor from detecting pedestrians,
cyclists, large animals or other vehicles
correctly.
•
Other vehicles can only be detected in
darkness if their headlights and taillights
are clearly visible.
•
The sensors have a limited range for
pedestrians and cyclists. The system
functions best at relative speeds up to
30 mph (50 km/h). For stationary or
slow-moving vehicles, the system func-
tions best at speeds up to approx.
43 mph (70 km/h).
•
If there is a risk of colliding with a large
animal, City Safety can reduce the vehi-
cle's speed by up to 9 mph (15 km/h).
Warnings and braking are most effective
at speeds above 43 mph (70 km/h) and
less effective at lower speeds.
WARNING
•
Warnings for stationary or slow-moving
vehicles and large animals may be impe-
ded by darkness or poor visibility.
•
Warnings and braking for pedestrians and
cyclists will not be provided at speeds
above approx. 43 mph (70 km/h).
