WHEELS AND TIRES }} * Option/accessory. 569 All tires gray: • Calibration in progress. • Status unknown. The vehicle may need to be driven for a few All tires gray and a message: • Tire pressure system
Temporarily unavailable . The indicator symbol will flash for about 1 minute and then glow steadily. • Tire pressure system
Service required . The indicator symbol will flash for about 1 12 . Related information • Calibrating the tire pressure monitoring sys- • Action when warned of low tire pressure • Tire pressure monitoring system* (p. 565) • Action when warned of low tire pressure When the system for monitoring inflation pres- 13 detects low inflation pressure in a tire, immediate action is required. If the system's indicator symbol illumi- Tire pressure low is displayed, check the tire pres- sure and inflate if necessary. 1. Switch off the ignition. 2. Check the inflation pressure on all four tires using a tire pressure gauge. 3. Inflate the tire to the correct inflation pres- sure; see the tire pressure placard on the 4. Through calibration of the system via the center display after the tire pressure has Please be aware that the indicator symbol To help prevent incorrect inflation pressure, • After inflating a tire, always replace the • Use plastic valve caps only. Metal caps WARNING • Incorrect inflation pressure could lead to • The system cannot predict sudden tire 11 The illustration is generic. Layout may vary depending on vehicle model or software version. 12 An authorized Volvo workshop is recommended. 13 Tire Pressure Monitoring System (TPMS) |
