Fig. 16: Installing Connecting Union With Thermostat
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Install connecting union -2- with thermostat -4- into engine block.

z

Tighten securing bolts -1-.

Tightening torque: 15 N.m

z

Fill with coolant. See COOLANT, DRAINING AND FILLING .

GLOW PLUGS, CHECKING

Special tools and equipment

z

V.A.G 1594 A Adapter set

Fig. 17: Identifying Special Tools And Equipment (V.A.G 1594 Adapter Set)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1527 B Diode test lamp



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 18: Identifying Special Tools And Equipment (V.A.G 1527 B Diode Test Lamp)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Battery voltage at least 11.5 V

z

Ignition switched off

Work sequence

Checking electric activation of glow plugs:

z

Disconnect connector -1- from glow plugs.

z

Connect diode test lamp cable with clamps from adapter set to battery positive (+).

z

Insert diode test lamp test pick to every glow plug one after another.

Fig. 19: Using Diode Test Lamp To Check Glow Plug
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



Diode lights up: glow plug is OK

Diode does not light up:

z

Replace glow plug. See GLOW PLUGS, CHECKING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



1998-2004 ENGINE

Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)

COOLING SYSTEM, SERVICING

COOLING SYSTEM, GENERAL INFORMATION

Perform cooling system leakage test with cooling system tester V.A.G 1274 and adapters V.A.G 1274/8 and

WARNING:

When performing repair work, especially due to the confined conditions
in the engine compartment, pay attention to the following:

z

Route all types of lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.

NOTE:

z

When the engine is warm the cooling system is under pressure. If
necessary release the pressure before beginning repair work.

z

Hoses are secured with spring-type clamps. In cases of repair only use
spring-type clamps.

z

Assembly tool VAS 5024 or hose clip pliers V.A.G 1921 are recommended
for installing spring-type clamps.

Fig. 1: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

When installing coolant hoses route stress-free so that they do not come
into contact with other components (observe markings on coolant
connection and hose).
