Volkswagen New Beetle. Manual - part 902





Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with engine codes: AWP (only manual transmission), AWV (manual and automatic transmission)

1. Expansion tank

2. Turbocharger

3. Intake manifold

4. Cylinder head/cylinder block

5. Upper coolant pipe

6. Connection

7. Heating system heat exchanger

8. Lower coolant pipe

9. ATF oil cooler

z

Only on vehicles with automatic transmission

10. Oil cooler

11. Upper coolant hose

12. Drain plug

13. Radiator

14. Lower coolant hose

15. After-run coolant pump -V51-

16. Coolant thermostat housing

17. Coolant pump

NOTE:

The following list refers to items in Fig. 4 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 4: Coolant Hose Connection Diagram - Engine Code AWP, AWV
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLING SYSTEM, DRAINING AND FILLING

Special tools and equipment

z

T10007 Refractometer

z

VAG 1306 Drip tray

z

VAS 5024 Assembly tool for spring-type clamps



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 5: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Draining

z

Open cap on coolant expansion tank.

z

Remove center insulation tray:

See PLENUM CHAMBER SEALING ASSEMBLY, REMOVING AND INSTALLING .

z

To drain coolant from radiator remove drain plug -arrow-.

WARNING:

Steam can be released when removing the cap from the expansion tank.
Cover cap with a cloth and open carefully.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 6: Draining Coolant From Radiator By Removing Drain Plug
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

To drain coolant from engine also remove coolant hose from oil cooler -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)
