Volkswagen New Beetle. Manual - part 776





2. ABS Control Module (w/EDL) -J104-

z

Location: on hydraulic unit on left of engine compartment

z

Checked by On Board Diagnostic (OBD)

z

Checking the multi-pin connector to control module, see MULTI-PIN CONNECTOR WITH
CONTACT ASSIGNMENTS


z

Do not disconnect multi-pin connector before successfully completing OBD. Switch ignition off
before separating connection.

z

Removing and installing

See HYDRAULIC UNIT, BRAKE BOOSTER/BRAKE MASTER CYLINDER ASSEMBLY
OVERVIEW MARK 60
 ; CONTROL MODULE AND HYDRAULIC UNIT, REMOVING
AND INSTALLING
 .

Vehicles with ABS/ESP only

z

When the ABS Control Module (w/EDL)-J104- is replaced, a zero compensation must be
performed

z

Initiate basic settings, see INITIATING BASIC SETTING Perform display group numbers 060,
063 and 066

3. Brake light switch -F-

z

The brake light switch is open in the rest position;

z

Adjusting, see ADJUSTING BRAKE LIGHT SWITCH

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK, READING

4. Sender for rotation rate -G202-

z

Vehicles with ABS/EDL/ASR/ESP only

z

Location: Under instrument panel next to steering column

z

Checked by OBD

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK,
READING


z

Observe installation instructions

See ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING .

5. Sensor for transverse acceleration -G200-

z

Vehicles with ABS/EDL/ASR/ESP only

z

Location: Under instrument panel next to steering column

z

Checked by OBD

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK,
READING


z

Observe installation instructions



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



See ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING .

z

When the sensor for transverse acceleration -G200- is replaced, a zero compensation must be
performed

z

Initiate basic setting, see INITIATING BASIC SETTING , perform display group number
063

6. ESP-Sensor unit -G419-, vehicles from my 12.01

z

Vehicles with ABS/EDL/ASR/ESP only

z

Combined sensor for transverse acceleration -G200- and sender for rotation rate -G202-

z

Assembled together in one housing

z

Checked by OBD

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK,
READING


z

Observe installation instructions

See ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING .

z

When the ESP-sensor unit -G419- is replaced, a zero compensation must be performed

z

Initiate basic setting, see INITIATING BASIC SETTING , perform display group number
063

7. Brake system vacuum pump -V192-

z

Not installed in all vehicles

z

Location: left of subframe

z

Checked by On Board Diagnostic (OBD) in engine control module

z

Removing and installing. See VACUUM PUMP (DIESEL MODELS) .

z

Checking

See ELECTRIC VACUUM PUMP .

8. Brake booster

9. Steering angle sensor -G85-

z

Vehicles with ABS/EDL/ASR/ESP only

z

Location: On steering column between steering wheel and steering column switch.

z

Checked by On Board Diagnostic (OBD)

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK,
READING
 .

z

Observe installation instructions

See ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



z

When the steering angle sensor -G85- is replaced, a zero compensation must be performed

z

Introduce basic setting, see INITIATING BASIC SETTING , perform display group
number 060

10. Sender 1 for brake booster -G201-

z

Vehicles with ABS/EDL/ASR/ESP only

z

Checked by OBD

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK,
READING


z

Removing and installing

See HYDRAULIC UNIT, BRAKE BOOSTER/BRAKE MASTER CYLINDER -
ASSEMBLY OVERVIEW MARK 60
 .

z

When the sender 1 for brake booster -G201- is replaced, a zero compensation must be
performed

z

Initiate basic setting, see INITIATING BASIC SETTING , perform display group number
066

11. Warning light for brake system -K118-

z

Location: In the instrument cluster

Function:, see DIAGNOSIS TROUBLE CODES (DTCS) DISPLAYED BY WARNING
LIGHTS -K47-, -K118- AND -K155-


12. ABS warning light -K47-

z

Location: In the instrument cluster

Function:, see DIAGNOSIS TROUBLE CODES (DTCS) DISPLAYED BY WARNING
LIGHTS -K47-, -K118- AND -K155-
 .

13. Right/left rear ABS wheel speed sensor -G44-/-G46-

z

Checked by OBD

z

Before inserting the sensor clean the inner surface of the sensor mounting and coat with lubricating
paste G 000 650

z

When connecting the speed sensor wire make sure it is not twisted in the wheel housing

z

Tightening torque of bolt: 10 N.m (7.4 ft lb)

14. ESP control lamp -K155-

z

Location: In the instrument cluster

Function:, see DIAGNOSIS TROUBLE CODES (DTCS) DISPLAYED BY WARNING
LIGHTS -K47-, -K118- AND -K155-
 .

15. Wheel hub with rotor for speed sensors



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



z

Rotor and speed sensors for rear left and right-hand sides are identical

z

Removing and installing

For rear suspension, see WHEEL BEARING .

16. Wheel hub with rotor for speed sensors

z

Rotor and speed senders for front left and right-hand sides are identical

z

Removing and installing

For front suspension, see WHEEL BEARING (WHEEL BEARING HOUSING
INSTALLED)
 .

17. Right/left front ABS wheel speed sensor -G45- / -G47-

z

Checked by OBD

z

Before inserting the sensor clean the inner surface of the sensor mounting and coat with lubricating
paste G 000 650

z

When connecting the speed sensor wire make sure it is not twisted in the wheel housing

z

Tightening torque of bolt: 10 N.m (7.4 ft lb)

18. Data Link Connector (DLC)

z

Location: on left below drivers stowage compartment

Fig. 150: Identifying Electrical/Electronic Components And Installing Locations (ABS Mark 60)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DIAGNOSIS TROUBLE CODES (DTCS) DISPLAYED BY WARNING LIGHTS -
K47-, -K118- AND -K155-

WARNING LAMPS



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle
