1998-2004 BRAKES

On Board Diagnostic (OBD) - New Beetle

ITT MARK 20 IE ON BOARD DIAGNOSTIC (OBD), GENERAL INFORMATION

FUNCTION

Since the control modules are interconnected with a Controller Area Network bus (CAN-bus), always start
troubleshooting by pressing buttons -0- and -0- to insert "Automatic Test Sequence" address word 00. This
checks DTC memory for all control modules in the vehicle, including those that may influence the ABS system
in case of malfunction.

On Board Diagnostic (OBD) relates to the electrical and electronic components of the ABS; in other words,
only malfunctions pertaining to the electrical connections to the control module are recognized (e.g. wheel
speed sensor, open circuit).

The 25-pin ABS Control Module (w/EDL) -J104- and the ABS hydraulic unit together form a compact module.
The control module is equipped with DTC memory, and is located on the left side of the engine compartment.
The Data Link Connector (DLC) is located left of the steering column under the instrument panel. Only early
production cars DLC is in the center console below the heating and air conditioning controls.

The control module recognizes malfunctions during vehicle operation and stores them as Diagnostic Trouble
Codes (DTC) in permanent memory. The DTCs remain in memory if the voltage from the battery is interrupted.

Sporadic malfunctions will also be recognized and stored. If these do not occur again within the next 50 vehicle
starts and driving cycles DTC memory will be erased (with the exception of "Control Module Malfunctioning").

Sporadic malfunctions are identified as such by "/SP" appearing on the VAG1551 Scan Tool (ST) display.

After switching the ignition on and/or starting the engine, ABS warning light -K47- and brake system warning
lamp -K118- (red) lights up for approx. 2 seconds. During this period a test sequence (self-test) is run in the
control module, checking the following:

z

Voltage supply (at least 10.0 volts)

z

Control module, including valve windings

z

Wheel speed sensor; electrical check fully completed at 20 km/h (approx. 13 mph)

z

Control module coding

z

If after driving off and exceeding a speed of approx. 20 km/h (approx. 13 MPH) the speed signal is not
OK. The ABS warning light -K47- will light up again.

VAG1551 Scan Tool (ST) or tester VAS 5051

The On Board Diagnostic (OBD) program must be initiated at the start of troubleshooting. Electrical
malfunctions which influence braking characteristics will be stored, and can only be checked with the



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



VAG1551 Scan Tool (ST) or with the tester VAS 5051.

The following procedures refer only to the VAG1551 scan tool.

The malfunction information displayed is used in conjunction with a DTC table, which has information on the
possible cause of malfunctions and specific corrective actions.

IDENTIFICATION

Left-hand drive

The brake booster boost is produced by vacuum pressure.

Distinguishing features:

1. 10" brake booster

2. Hydraulic unit

3. Control module, 25-pin (bolted to hydraulic unit)

Fig. 1: Identifying ABS Left-Hand Drive Distinguishing Features (ITT Mark 20 IE)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Right-hand drive

The brake booster boost is produced by vacuum pressure.

Distinguishing features:

1. 7"/8" brake booster

2. Hydraulic unit

3. Control module, 25-pin (bolted to hydraulic unit)



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 2: Identifying ABS Right-Hand Drive Distinguishing Features (ITT Mark 20 IE)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Distinguishing features of ABS & ABS/EDL (ITT Mark 20 IE hydraulic unit), left and right-hand drive

z

Dimension -A-: 100 mm (vehicles with ABS)

z

Dimension -A-: 130 mm (vehicles with ABS/EDL)

z

Dimension -A: -130 mm vehicles with ABS/EDL/ASR

Fig. 3: Distinguishing Features Of ABS & ABS/EDL (ITT Mark 20 IE hydraulic unit) - Left And
Right-Hand Drive

Courtesy of VOLKSWAGEN OF AMERICA, INC.

TECHNICAL DATA

ABS Control Module (w/EDL) -J104-

When checking DTC memory, the control module identification will be displayed on the VAG1551 scan tool.

1J0 907 379D: ABS

1J0 907 379 E: ABS/EDL

NOTE:

The following list refers to items in Fig. 3 .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



1 J0 907 379 R / J - ABS/EDL/ASR

Diagnostic Trouble Code (DTC) memory

Permanent memory (DTC memory) contents remain even without a supply voltage.

Data output

Data output is achieved using "Rapid data transfer" operating mode 1.

SAFETY PRECAUTIONS AND GENERAL TROUBLESHOOTING INFORMATION

Necessary technical information

See SYSTEM WIRING DIAGRAMS in ELECTRICAL.

See DISC and ANTI-LOCK BRAKE SYSTEM .

Road test

CAUTION:

z

ABS is a vehicle safety system; the appropriate knowledge is
necessary to work on the system.

z

In order to check complaints and to be able to carry out specific
troubleshooting, DTC memory must be checked before beginning
work on the ABS system.

z

Only disconnect harness connectors when the ignition is switched
off.

z

Observe the appropriate instructions regarding the handling of brake
fluid, see SAFETY PRECAUTIONS .

See .

z

ABS malfunctions are indicated by the ABS warning lamp lighting
up; certain malfunctions will only be recognized at speeds above 20
km/h (approx. 13 mph) (road test).

z

If the ABS Warning Light -K47- and the warning light for brake
system -K118- warning lamps do not light up, but the brake system is
not functioning correctly, check the conventional braking system.

WARNING:

z

If you drive the vehicle after a malfunction has been detected by
OBD, bear in mind that the function of the brake system is limited,
and there is a risk of accident. The brake pressure at the rear wheels
is no longer controlled by the Electronic Brake Distribution (EBD)
function. This can result in excessive braking at the rear, and the
vehicle may skid unexpectedly under braking.



2003 Volkswagen New Beetle GLS
