z

Used to secure the wiring harness

23. Self-locking hex nut, 20 N.m (15 ft. lb)

24. Brake master cylinder, right-hand drive (RHD)

z

Must not be repaired. If faulty, replace complete.

25. Sender 1 for brake booster -G201-

26. Bolt

z

To secure brake fluid reservoir to brake master cylinder

27. Seal

z

Always replace

28. Brake booster, right-hand drive

29. Seal

z

For brake booster

30. Self-locking hex nut, 20 N.m (15 ft. lb)

31. Boots

z

Make sure boots seats correctly otherwise there is a danger of suction noises

32. Retainer

z

Secured to edge of brake booster

33. Heat shield

z

Application

z

See Parts catalog

34. Retainer

z

Used to secure the wiring harness

35. Sealing plug



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 38: Identifying Hydraulic Unit, Brake Booster/Brake Master Cylinder Assembly - Mark 60 ABS
Courtesy of VOLKSWAGEN OF AMERICA, INC.

CONTROL MODULE AND HYDRAULIC UNIT, REMOVING AND INSTALLING

Special tools and equipment

z

VAG 1331 Torque wrench or equivalent

z

VAG 1410 Torque wrench or equivalent

z

VAG 1869/2 Brake pedal depressor or equivalent



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 39: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Location:

The control module is screwed to the hydraulic unit and is located on left in the engine compartment.

Removing

z

Obtain radio code on vehicles with coded radio.

z

Disconnect battery.

z

Remove intake hose -1- and connector -2- off mass air flow sensor.

z

Remove bolts -3-, -4- and -5-.

z

Take out air cleaner complete.

WARNING:

Do not bend the brake lines in the area of the hydraulic unit!



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 40: Removing Intake Hose And Connector Off Mass Air Flow Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

If installed, remove relay protective housing -1- from cable channel.

z

Draw off as much brake fluid as possible from brake fluid reservoir using a suction bottle.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
