z

Align side window -2- parallel with door window -1-. Dimension -A- = 9 mm.

Fig. 33: Loosening Combi-Nuts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press side window lightly into window guide -arrow B-.

NOTE:

The side window can now be moved up and down as well as forward and
back.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 34: Pressing Side Window Lightly Into Window Guide
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten combi-nuts (20 N.m) through assembly opening -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 35: Tightening Combi-Nuts Through Assembly Opening
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Adjusting side inclination (distance)

z

Remove window slot inner seal.

z

Remove bolts/screws -1-.

NOTE:

The side window must be installed.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 36: Removing Window Bolts/Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lower door window to approx. central position until the combi-nut is visible in the assembly opening -
arrow-.

z

Tighten combi-nut.

z

Then perform functional check.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle
