Removing z Remove rear inner fender liner. See REAR WHEEL HOUSINGS LINER, ASSEMBLY OVERVIEW . z Turn bulb holder in direction shown -arrow- and pull out from housing. Fig. 83: Removing Rear Side Marker Light Bulb From Holder z Pull out bulb (12V/5W), do not turn. Installing CAUTION: z Switch off all electrical consumers. z Switch ignition off and remove ignition key. CAUTION: Do not touch the glass portion of the bulb with bare hands. The moisture and/or grease from fingers that evaporates on the bulb during operation
2003 Volkswagen New Beetle GLS 1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Exterior - New Beetle
|
