Volkswagen New Beetle. Manual - part 2513





A. Internal extractor, e.g. Kukko 21/3, 18.5... 23.5 mm

Pressing ball sleeve into selector mechanism cover

Fig. 69: Pressing Ball Sleeve Into Selector Mechanism Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing oil seal onto stop



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 70: Installing Oil Seal Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Selector mechanism cover and selector shaft changed



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 71: Installing Selector Mechanism Cover And Selector Shaft Changed
Courtesy of VOLKSWAGEN OF AMERICA, INC.


As of date of manufacture of September 4th 2000 the bolt -2- is installed into the selector mechanism cover -1-.

Tightening torque

15 N.m

The selector shaft locating sleeve has been equipped with the segment -3-.

Function

When shifting down from the 5th to 4th gear the bolt -2- guides the selector shaft via the segment -3- into the
4th gear gap.

Selector mechanism cover and selector shaft changed



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
