Volkswagen New Beetle. Manual - part 2451





Fig. 58: Installing Sleeve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

A. Screw threaded rod from assembly tool 3066 into differential threaded piece

B. Nut M12 with washer

z

Pull sleeve in onto stop with thrust piece 3124 by turning on nut -B-.

NOTE:

When transmission is disassembled press sleeve in with thrust piece 3124
onto stop.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Pulling out sleeve and oil seal

Fig. 59: Pulling Out Sleeve And Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

There is a step in inner diameter from sleeve

z

For pulling out sleeve and oil seal, apply the pulling hook VW 771/37 at the back of the step in the
sleeve.

z

While pulling out press forcibly the pulling hook VW 771/37 into the sleeve.

Driving in sleeve and oil seal



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 60: Driving In Sleeve And Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Clean the sitting place of oil seal in transmission.

A. Screw threaded rod from assembly tool 3066 into differential threaded piece

B. Nut M12

z

Drive sleeve over press piece T10148 onto stop by turning on nut -B-.

SELECTOR MECHANISM ON TRANSMISSION SIDE, UP TO 05.99, DISASSEMBLING AND
ASSEMBLING

NOTE:

When transmission is disassembled press sleeve in with press piece
T10148 onto stop.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Special tools and equipment

z

VW 439 Guide pin

z

VW 402 Press plate

z

VW 408 A Press tool

z

VW 447 H Press plate

z

3129 Fitting tool

Fig. 61: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Selector shaft

2. Stop ring

NOTE:

The following list refers to items in Fig. 62 .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
