Fig. 6: Identifying Oil Seal Lip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

After installation:

Check transmission oil; if necessary top-off to lower edge of oil filler hole, specification. See CODE
LETTERS, TRANSMISSION APPLICATION, RATIOS, CAPACITIES
 .

Locking devices



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Replace circlips.

z

Do not overstretch circlips.

z

Circlips must be install properly in the groove.

z

Replace spring pins. Installation position: Slot longitudinal to line of force.

Fig. 7: Replacing Circlips
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Bolts and nuts

z

Tighten and loosen bolts and nuts for securing covers and housings in a diagonal sequence.

z

Delicate parts, must not be distorted, such as clutch pressure plates. Loosen and tighten nuts and bolts in



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



stages in a diagonal sequence.

z

Tightening torques as specified are for unoiled bolts and nuts.

z

Replace self-locking bolts and nuts.

z

Make sure with threaded connections that the areas of the contact surfaces as well as the visible surfaces
of nuts and bolts are rewaxed after assembly.

Bearings

z

Install new tapered roller bearings as supplied and do not lubricate.

z

Install needle bearings with lettered side (thicker metal) toward installing tool.

z

Tapered roller bearings installed to one shaft must be replaced as a set. Use same make of bearings.

z

Heat inner races to approx. 100 °C before installing.

Shims

z

Measure shims at several points with a micrometer. Tolerance variations make it possible to find the
exact shim thickness required.

z

Check for burrs and damage.

z

Only install perfect shims.

Synchronizer rings

z

Do not interchange. When reusing always install to the same gear.

z

Check for wear and replace if necessary.

z

Coat with gear oil before installing.

Gear wheels

z

Before installing clean and heat on a hot plate to approx. 100° C.

z

Temperature can be checked with temperature tester V.A.G 1558.

MANUAL TRANSMISSION - CONTROLS, HOUSING

TRANSMISSION, DISASSEMBLING AND ASSEMBLING

Transmission overview

1. 1st gear

2. 2nd gear

3. 3rd gear

4. 4th gear

NOTE:

The following list refers to items in Fig. 8 .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



5. 5th gear

6. Transmission housing

z

Servicing. See TRANSMISSION HOUSING AND CLUTCH HOUSING, SERVICING

7. Selector mechanism

z

(Selector forks)

z

Disassembling and assembling. See SELECTOR FORKS, DISASSEMBLING AND
ASSEMBLING


8. Input gear for 1st and reverse gear

9. Input shaft

z

Disassembling and assembling. See INPUT SHAFT, DISASSEMBLING AND ASSEMBLING

10. Output shaft

z

Disassembling and assembling. See Output shaft, disassembling and assembling

11. Differential

z

Disassembling and assembling. See Differential, disassembling and assembling

12. Clutch housing

z

Servicing. See TRANSMISSION HOUSING AND CLUTCH HOUSING, SERVICING
