z

Tighten shear head bolt -10- until head shears off.

z

Install steering column with preassembled steering lock housing to cross member.

z

Install hex bolts -5-.

z

Now insert hex bolt -12-.

z

Install nut -13- and tighten to 10 N.m (7.4 in lb).

z

Now tighten bolts -5- to 25 N.m (18 ft lb).

z

Now pull out transportation securing device -6-.

z

Install universal joint shaft onto steering pinion -9-.

z

Tighten bolt 8 to 30 N.m (22 ft lb).

1. Cross member for steering column

2. Steering column

3. Screw

4. Handle

5. Hex. bolts

z

25 N.m (18 ft lb)

6. Transportation securing device

7. Steering column drive shaft

8. Hex. bolt

z

30 N.m (22 ft lb)

9. Steering gear pinion

10. Shear head bolt

11. Roller

12. Hex bolt

13. Hex. nut

z

10 N.m (7.4 in lb)

NOTE:

The following list refers to items in Fig. 12 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 12: Installing Steering Column From Cross Member (Manufactured By Nacam)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with the steering column from the company Presta from 02.00 and up

New steering columns, which are delivered as spare parts, are secured with a transportation securing device -6-.

This transportation device 6 must be removed after installing steering column in vehicle .

The shear head bolt -10- and the roller -11- must be installed on new steering columns, which have been
supplied as a spare part
 .

z

Tighten shear head bolt -10- until head shears off.

z

Install steering column with preassembled steering lock housing to cross member.

z

Install bolts -5-.

NOTE:

The following list refers to items in Fig. 13 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

Now insert hex bolt -12-.

z

Install nut -13- and tighten to 10 N.m (7.4 ft lb).

z

Now tighten bolts -5- to 25 N.m (18.4 ft lb).

z

Now pull out transportation securing device -6-.

z

Install universal joint shaft onto steering pinion.

z

Tighten bolt -8- to 30 N.m.

1. Cross member for steering column

2. Steering column

3. Bolts

4. Handle

5. Hex bolt

z

25 N.m (18 ft lb)

z

Inserted with locking fluid

„

Use locking fluid D 000 600

6. Transportation securing device

7. Steering column universal joint shaft

8. Hex bolt

z

30 N.m (22 ft lb)

9. Steering gear pinion

10. Shear head bolt

11. Roller

12. Hex bolt

13. Hex nut

z

10 N.m (7.4 in lb)

NOTE:

The following list refers to items in Fig. 13 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 13: Installing Steering Column From Cross Member (Manufactured By Presta)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continued for all vehicles

The ignition key removal lock cable must also be hooked-on, vehicles with an automatic transmission. See
HOOKING .

z

Installing steering lock switch.

See STEERING COLUMN SWITCHES, REMOVING AND INSTALLING .

z

Install steering angle sensor -G85-.

See STEERING ANGLE SENSOR -G85-, REMOVING AND INSTALLING .
