Volkswagen New Beetle. Manual - part 2062





Fig. 47: Clamping Suction Hose With Hose Clamp 3094
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

Place drip tray underneath.

z

Disconnect bracket for pump pressure line from cylinder block.

z

Disconnect pump pressure line.

z

Install adapter -1-.

Use a sealing ring.

1. V.A.G 1402/1 A

2. V.A.G 1402/6 Hose from adapter set

Fig. 48: Installing Adapter V.A.G 1402
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect pressure gauge V.A.G 1402.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



1. V.A.G 1402 Pressure gauge

2. V.A.G 1402/6 Hose from adapter set

3. Banjo union bolt

4. Pressure hose banjo union

5. V.A.G 1402/2

6. V.A.G 1402 Hose from pressure gauge

Fig. 49: Connecting Power Steering Pressure Gauge (Vehicles With Power Steering Pump In
Lower Section)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove hose clamp 3094 from suction and return hoses.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

Start engine and if necessary add fluid to reservoir.

z

Turn steering wheel approx. 10 times from lock to lock.

z

Now check delivery pressure.

Requirements:

z

Ribbed belt/ribbed belt tension OK.

z

System not leaking.

z

Hoses/lines are not kinked or restricted.

{

With engine running at idle speed. Close cut-off valve (not longer than 5 seconds) and read off
pressure.

Specifications

Gasoline engines: 85...95 bar (1233 - 1378 psi)

Diesel engines: 96... 105 bar (1392 - 1523 psi)

POWER STEERING PUMP DELIVERY PRESSURE, VEHICLES WITH POWER STEERING PUMP
IN UPPER SECTION, CHECKING

Special tools and equipment

z

3094 Hose clamps

z

V.A.G 1402 Power steering test unit

z

V.A.G 1402/1 A Adapter

z

V.A.G 1402/2 Adapter

z

V.A.G 1402/6 Hose from adapter set

NOTE:

z

If the reading is higher or lower than specified, replace power steering
pump.

z

Removing and installing power steering pump, vehicles with power
steering pump in lower section. See POWER STEERING PUMP: VEHICLES
WITH POWER STEERING PUMP IN LOWER SECTION, REMOVING AND
INSTALLING .

z

If reservoir fluid level is low then check steering system for leaks.

z

For leaks at the pinion first check the lines/line connections for leaks and
if necessary tighten and wipe dry.

z

If the pinion seal or the rack seals in steering gear housing are leaking
then replace steering gear.

z

To check the rack seals loosen the hose clip on the boot and push boot to
one side.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
