CAUTION: Before beginning repairs on the electrical system:

z

Obtain the anti-theft radio security code.

z

Switch the ignition off.

z

Disconnect the battery Ground (GND) strap.

z

After reconnecting battery, re-code and check operation of anti-theft
radio. Also check operation of clock and power windows according
to Repair Manual and/or Owner's Manual.

z

Immediately plug open connections on A/C components to prevent
dirt and moisture contamination.

NOTE:

z

Before carrying out any work on the A/C refrigerant system, refer to A/C
refrigerant system safety measures, See A/C refrigerant system .

z

Except where indicated with *, all system components illustrated must
only be serviced or replaced after discharging refrigerant system.

NOTE:

During servicing, all couplings, fittings and related fasteners must be torqued to
specifications.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 20: Identifying A/C Refrigerant System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The following list refers to items in Fig. 20 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



1. Sealing plug

z

15 N.m (11 ft. lb)

2. O-ring

z

10.8 mm; 1.8 mm

3. Receiver drier

4. O-ring

z

10.8 mm; 1.8 mm

5. Refrigerant pipe

z

From receiver drier to expansion valve

6. Bolt

z

15 N.m (11 ft. lb)

7. A/C pressure switch -F129- (4-Pin) or high pressure sensor -G65- (3-Pin)

z

Depending on engine type, refrigerant systems have either an A/C pressure switch -F129- or high
pressure sensor -G65- instralled. Refer to system wiring diagrams.

z

Checking -F129-, See A/C pressure switch -F129-, checking .

z

Checking -G65-, See High pressure sensor -G65-

z

Removing and installing, See Removing And Installing A/C Pressure Switch -F129- And High
Pressure Sensor -G65-


z

Component can be removed without discharging refrigerant system

8. O-ring

z

10.8 mm; 1.8 mm

9. Refrigerant pipe

10. Threaded plate

11. O-ring

z

10.8 mm; 1.8 mm

12. Expansion valve

13. Bolt

z

8 N.m (71 in lb)

14. O-ring

z

14 mm; 1.8 mm

15. High pressure service valve

z

Only use Kent Moore ACR4 or equivalent

16. Refrigerant pipe

17. Low pressure service valve

z

Only use Kent Moore ACR4 or equivalent

18. O-ring

z

7,6 mm; 1.8 mm

19. Evaporator



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



z

In heater/evaporator unit

z

Removing, See Heater/evaporator unit, disassembly and assembly

20. O-ring

z

16.7 mm; 1.8 mm

21. Insulation

22. O-ring

z

7,6 mm; 1,8 mm

23. Bolt

z

8 N.m (71 in lb)

24. Refrigerant hose

z

From compressor to condenser

25. Bolt

z

15 N.m (11 ft. lb)

26. O-ring

z

10.8 mm; 1.8 mm

27. Condenser

z

Removing and installing, See Condenser, removing and installing

28. Compressor

z

Sanden SD7-V16

z

Removing and installing compressor bracket, See Compressor bracket, removing and installing

29. O-ring

z

14.3 mm; 2.4 mm

30. Bolt

z

20 N.m (15 ft. lb)

31. O-ring

z

10.8 mm; 1.8 mm

32. A/C clutch -N25-*

z

Sanden

z

Servicing, See A/C clutch -N25-, servicing (Sanden)

33. Refrigerant hose

34. O-ring

z

10.8 mm; 1.8 mm

35. Damper

CONDENSER, REMOVING AND INSTALLING

First do the following:



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle
