Volkswagen New Beetle. Manual - part 1998





Fig. 3: Identifying Condenser
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Receiver drier

The receiver drier acts as a refrigerant reservoir for the system. Any moisture in the system is absorbed in the
drier desiccant.

Fig. 4: Identifying Receiver Drier
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Sight glass (if equipped)

NOTE:

The condenser for the R-134a refrigerant system is identified with a green label.

CAUTION: The receiver drier may be identified with a green R-134a label and MUST

NOT be used in R-12 systems (the drier desiccant inside is only
compatible with R-134a refrigerant). Likewise, NEVER use an R-12 receiver
drier in and R-134a system.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



With a properly charged A/C system and A/C clutch engaged, the sight glass -arrow- should remain clear and
bubble free.

Fig. 5: Locating Sight Glass
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Expansion valve

The expansion valve restricts and controls refrigerant flow to the evaporator thus lowering refrigerant
temperature and pressure.

Fig. 6: Identifying Expansion Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

z

The mixture of R-134a refrigerant and refrigerant (PAG) oil may appear
milky in the sight glass.

z

If equipped, sight glass location may not be as illustrated in Fig. 5 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Evaporator

Liquid refrigerant entering the evaporator absorbs heat from air passing through the evaporator fins and cools
the air. As the refrigerant absorbs heat it turns to vapor and then is suctioned by the compressor.

Fig. 7: Identifying Evaporator
Courtesy of VOLKSWAGEN OF AMERICA, INC.

O-rings

O-rings seal connections between A/C system components.

Fig. 8: Identifying Dimension Of O-Rings
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The R-134a expansion valve may be identified with a green label.

NOTE:

z

Always use correct size O-rings (dimensions -a- and -b-).

z

Do not reuse O-rings, always replace. Use only new O-rings that are



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Pressure relief valve

The pressure relief valve is mounted on the compressor or compressor inlet/outlet manifold. At pressures above
40 bar (580 psi), the pressure relief valve opens to vent excessive pressure. When the system pressure is
reduced, the valve closes to prevent total refrigerant loss.

Fig. 9: Identifying Pressure Relief Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

On some models, a cap on the pressure relief valve will pop out if the valve has opened.

A/C pressure switch -F129-

compatible with R-134a refrigerant and refrigerant (PAG) oil on R-134a
systems.

z

O-rings for use only on R-134a systems may be color coded: red, green,
violet or black.

z

Lubricate O-rings with the appropriate refrigerant oil before installing (only
use PAG oil).

NOTE:

Depending on engine type, refrigerant systems have either an A/C pressure
switch -F129- or high pressure sensor -G65- instralled. Refer to system wiring
diagrams.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle
