Volkswagen New Beetle. Manual - part 1962





Fig. 12: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

There must not be any DTCs stored in DTC memory, see DIAGNOSTIC MODE 3: CHECK DTC
MEMORY
 .

z

Intake air temperature 5 to 35 C, see DIAGNOSTIC MODE 1: CHECK MEASURED VALUES ; PID
15: Intake Air Temperature (IAT)

Work procedure

z

Connect diagnostic tester, see CONNECT DIAGNOSTIC TESTER .

z

Perform a road test.

The following operating condition must be met during this road test:

z

Coolant temperature must reach at least 80 C, see DIAGNOSTIC MODE 1: CHECK MEASURED
VALUES
 ; PID 5, Coolant temperature.

Observe the safety precautions that apply to road tests, see SAFETY PRECAUTIONS .

Let vehicle cool off with the ignition switched off until the following condition is met:

z

Coolant temperature approx. intake air temperature (5 to 35 °C), see DIAGNOSTIC MODE 1: CHECK
MEASURED VALUES
 ; PID 5, Coolant temperature.

z

Perform a road test anew.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



The following operating conditions must be met during this road test:

z

Accelerate vehicle uniformly, not at Wide Open Throttle (WOT).

z

Drive for 10 minutes in the highest gear or in the highest driving mode on a level driving surface at a
constant speed in the range of 65 to 80 km/h at an engine speed of 2000 to 2500 RPM.

z

After 10 minutes, downshift until an engine speed of 2800 to 3500 RPM has been reached.

z

Drive in deceleration mode at a speed up to approx. 1800 RPM.

z

Park vehicle and let engine run at idle for 3 minutes.

z

Accelerator pedal must not be operated during this time.

z

Perform a road test anew.

The following operating conditions must be met during this road test:

z

Accelerate vehicle uniformly, not at Wide Open Throttle (WOT).

z

Drive for 10 minutes in the highest gear or in the highest driving mode on a level driving surface at a
constant speed in the range of 65 to 80 km/h at an engine speed of 2000 to 2500 RPM.

z

Park vehicle and let engine run at idle for 3 minutes.

z

Accelerator pedal must not be operated during this time.

z

Read readiness code, see READ READINESS CODE .

If a 1 is displayed instead of a 0 in the 8-digit number block:

z

Perform a road test anew.

The following operating conditions must be met during this road test:

z

Drive for 10 minutes in the highest gear or in the highest driving mode on a level driving surface at a
constant speed in the range of 65 to 80 km/h at an engine speed of 2000 to 2500 RPM.

z

Park vehicle and let run at idle for 3 minutes.

z

Accelerator pedal must not be operated during this time.

z

Read readiness code, see READ READINESS CODE .

In 8-digit number block:

NOTE:

z

Vehicle speed, see DIAGNOSTIC MODE 1: CHECK MEASURED VALUES ;
PID 13, Vehicle speed.

z

Engine speed, see DIAGNOSTIC MODE 1: CHECK MEASURED VALUES ;
PID 12, engine rotations per minute (RPM).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



z

Display position 5: Secondary Air Injection (AIR) system

and/or

z

Display position 6: EVAP canister system

a 1 instead of 0 is displayed:

z

Repeat complete work procedure, see WORK PROCEDURE

DIAGNOSTIC TROUBLE CODE (DTC) TABLES:

SAE P0xxx-DTCs

Fuel and air mixture and additional emission regulations

DIAGNOSTIC TROUBLE CODE P0010 TO P0032

DIAGNOSTIC TROUBLE CODE P0036 TO P0038

SAE
DTC

DTC text

Corrective action

P0010

"A" Camshaft Position

Actuator Circuit Bank 1

z

Check Valve -1- for camshaft adjustment -N205-, see VALVE

FOR CAMSHAFT ADJUSTMENT, CHECKING

(VEHICLES WITH ENGINE CODE AWP, AWV)

P0011

"A" Camshaft Position -

Timing Over - Advanced

or System Performance

Bank 1

P0012

"A" Camshaft Position -

Timing Over - Retarded

Bank 1

P0016

Crankshaft Position -

Camshaft Position

Correlation Bank 1

Sensor A

z

Check Camshaft Position (CMP) Sensor -G40-or Camshaft

Position (CMP) Sensor 2 -G163-, see CHECK CAMSHAFT

POSITION (CMP) SENSOR

P0030

HO2S Heater Control

Circuit Bank 1 Sensor 1

z

Check oxygen sensor heater for Oxygen Sensor (O2S) before

Three Way Catalytic Converter (TWC), see OXYGEN

SENSOR HEATER FOR OXYGEN SENSOR BEFORE

THREE WAY CATALYTIC CONVERTER (TWC),

CHECKING

z

Check Oxygen Sensor (O2S) and oxygen sensor control before

Three Way Catalytic Converter (TWC), see CHECK

OXYGEN SENSOR AND OXYGEN SENSOR

REGULATION BEFORE CATALYTIC CONVERTER

P0031

HO2S Heater Control

Circuit Low Bank 1

Sensor 1

P0032

HO2S Heater Control

Circuit High Bank 1

Sensor 1

SAE
DTC

DTC text

Corrective action



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Fuel and air ratios

DIAGNOSTIC TROUBLE CODE P0101 TO P0113

1)

 Intake manifold pressure is determined by the Charge Air Pressure Sensor -G31- (instead of Manifold

Absolute Pressure (MAP) Sensor -G71- as indicated), air pressure is determined by the Barometric Pressure
(BARO) Sensor - F96- (in ECM).

DIAGNOSTIC TROUBLE CODE P0116 TO P0135

P0036

HO2S Heater

Control Circuit

Bank 1 Sensor 2

z

Check oxygen sensor heater for Oxygen Sensor (O2S) behind Three

Way Catalytic Converter (TWC), see OXYGEN SENSOR HEATER

FOR OXYGEN SENSORS BEHIND THREE WAY CATALYTIC

CONVERTER (TWC), CHECKING

z

Check Oxygen Sensor (O2S) and oxygen sensor control behind Three

Way Catalytic Converter (TWC), see CHECK OXYGEN SENSOR

AND OXYGEN SENSOR REGULATION BEHIND CATALYTIC

CONVERTER

P0037

HO2S Heater

Control Circuit

Low Bank 1

Sensor 2

P0038

HO2S Heater

Control Circuit

High Bank 1

Sensor 2

SAE
DTC

DTC text

Corrective action

P0101

Mass or Volume Air Flow

Circuit Range/Performance

z

Check Mass Air Flow (MAF) Sensor -G70-, see MASS

AIR FLOW (MAF) SENSOR, CHECKING

z

Check intake air system for leaks (false air), see

INTAKE SYSTEM FOR LEAKS (FALSE AIR),

CHECKING

P0102

Mass or Volume Air Flow

Circuit Low Input

P0103

Mass or Volume Air Flow

Circuit High Input

P0112

Intake Air Temperature Sensor

1 Circuit Low

z

Check Intake Air Temperature (IAT) Sensor -G42-, see

CHECKING INTAKE AIR TEMPERATURE (IAT)

SENSOR

P0113

Intake Air Temperature Sensor

1 Circuit High

SAE
DTC

DTC text

Corrective action

P0116 Engine Coolant Temperature

Circuit Range/Performance

z

Check Engine Coolant Temperature (ECT) Sensor -G62-,

see ENGINE COOLANT TEMPERATURE (ECT)

SENSOR, CHECKING

z

Check coolant regulator:

See COOLING SYSTEM COMPONENTS (ENGINE

SIDE)

P0117 Engine Coolant Temperature

Circuit Low

P0118 Engine Coolant Temperature

Circuit High

P0121

Throttle/Pedal Position

Sensor/Switch "A" Circuit

z

Check Throttle Valve Control Module -J338-, see

THROTTLE VALVE CONTROL MODULE,



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle
