Volkswagen New Beetle. Manual - part 1933





Selectable diagnostic modes under address word 33 - OBD

Diagnostic Modes Under Address Word 33

Control)

Control)

Equipment of control module for Diesel-Direct
fuel injection system

80

121

Emissions limiting values according to

Tier 1

(1)

Tier 1

(1)

On Board Diagnostic (OBD)

OBD II

OBD II

DTC memory

Permanent memory

(2)

Permanent memory

(2)

Memory for adaptation values

Temporary memory

(3)

Temporary memory

(3)

Intake manifold change-over

No

No

Camshaft adjustment

No

No

Boost pressure regulation

Yes

Yes

Exhaust Gas Recirculation (EGR)

Yes

Yes

(1)

Tier 1 = Non-Low Emission Vehicles (emission values max. 0.25 g/mi HC)

(2)

Independent of voltage supply.

(3)

Values are erased when voltage supply is interrupted.

NOTE:

The conditions required for selecting the desired diagnostic mode are listed in
the following table:

Diagnostic mode

Requirement:

Selectable diagnostic modes under address word 33-
OBD

z

engine

off

z

Ignition

switched

on

z

Engine

running

at idle

z

Vehicle

in drive

mode

Mode
1:

Check measured

values

See DIAGNOSTIC MODE

1: CHECK MEASURED

VALUES .

Yes

Yes

Yes

Mode
2:

Check operating

conditions

See DIAGNOSTIC MODE

2: CHECK OPERATING

CONDITIONS .

Yes

Yes

Yes

Mode
3:

Check DTC

Memory

See DIAGNOSTIC MODE

3: CHECK DTC

MEMORY .

Yes

(1)

Yes

Yes

Mode
4:

Reset/erase

diagnostic data

See DIAGNOSTIC MODE

4: RESET/ERASE

DIAGNOSTIC DATA .

Yes

Yes

Yes

Mode
6:

Check test results

of components

See DIAGNOSTIC MODE

6: CHECK TEST

Yes

(2)

Yes

(2)

Yes

(2)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Diagnostic Tester, connecting

Recommended special tools and equipment:

z

VAS 5052 Vehicle Diagnostic and Information System with

Fig. 1: Identifying Special Tool VAS 5052
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAS 5052/3 diagnostic cable

Requirements

z

The respective fuses of Diesel-Direct fuel injection system must be OK.

that are not

continuously

monitored

RESULTS OF

COMPONENTS THAT

ARE NOT

CONTINUOUSLY

MONITORED .

Mode
7:

Check test results

of components

that are

continuously

monitored

See DIAGNOSTIC MODE

7: CHECK TEST

RESULTS OF

COMPONENTS THAT

ARE CONTINUOUSLY

MONITORED .

Yes

(1)

Yes

Yes

Mode
9:

Vehicle

information

See DIAGNOSTIC MODE

9: VEHICLE

INFORMATION .

Yes

Yes

Yes

(1)

Perform only with ignition switched on when engine does not start (operate starter beforehand for at
least 6 seconds).

(2)

Test-ID 10 and Test-ID 12 can only be performed with engine at standstill and ignition switched on.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Fig. 2: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 Volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

Parking brake must be engaged or else daylight driving lights will be switched on.

z

For vehicles with automatic transmission, selector lever must be in position -P- or -N-.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

Ignition switched off.

Work procedure

Connect diagnostic tester (VAS 5052) using (VAS 5052/3) diagnostic cable as follows:

z

Connect diagnostic cable connector to Data Link Connector (DLC) -arrow-.

NOTE:

Fuse holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Fig. 3: Locating Data Link Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Depending on the desired diagnostic mode, it is necessary to:switch on ignition or start engine and let it
run at idle. See Selectable diagnostic modes under address word 33 - OBD .

Test box, connecting for wiring test

Recommended special tools and equipment:

Vehicles with 80-pin control module

z

VAG1598/22 test box

NOTE:

z

Respective operation of the diagnostic tester:

z

If no display appears on diagnostic tester, check voltage supply at
Diagnostic Link Connector (DLC).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle
