Volkswagen New Beetle. Manual - part 1921





Fig. 1: Identifying VAS 5052 Vehicle Diagnostic And Information System
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

The respective fuses of the Motronic fuel injection and ignition system must be OK. Fuse holder is
located behind access panel at far left end of dash.

Fig. 2: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

Parking brake must be engaged or else daylight driving lights will be switched on.

z

For vehicles with automatic transmission, selector lever must be in position -P- or -N-.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

Ignition switched off.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Work procedure

Connect diagnostic tester (VAS 5052) using (VAS 5052/3) diagnostic cable as follows:

z

Connect diagnostic cable connector to Data Link Connector (DLC) -arrow-.

Fig. 3: Identifying Data Link Connector (DLC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Depending on the desired diagnostic mode, it is necessary to:switch on ignition

or start engine, see SELECTABLE DIAGNOSTIC MODES UNDER ADDRESS WORD 33 - OBD .

Connect test box for wiring test

Recommended special tools and equipment

z

VAG1598/31 test box

NOTE:

z

Respective operation of the diagnostic tester:

See Operating instructions of the diagnostic tester

z

If no display appears on diagnostic tester, check voltage supply at
Diagnostic Link Connector (DLC).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Fig. 4: Identifying VAG1598/31 Test Box
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirement

z

Ignition switched off.

Work procedure

z

Remove inner cover, left plenum chamber, to do this, slide center cover -1- of plenum chamber forward
out of catch and remove from instrument panel.

Fig. 5: Removing Inner Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove three bolts -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Fig. 6: [Removing Three Bolts]
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift left cover -1- of plenum chamber in center of instrument panel (arrow A) and thereby unclip (front
edge clips, rear edge clamps).

z

Pull cover -1- toward vehicle center out of bracket underneath Apillar (arrow B).

z

Then disengage connector from control module and disconnect.

Fig. 7: Pulling Cover Toward Vehicle Center Out Of Bracket Underneath A Pillar
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect VAG1598/31 test box at control module wiring harness. Engine Control Module (ECM) is not
connected.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle
