Test data, spark plugs TEST DATA, SPARK PLUGS See MAINTENANCE Camshaft Position (CMP) sensor -G40-, checking Special tools, test equipment and auxiliary items z V.A.G 1598/31 test box z V.A.G 1526 A or Fluke 83 multimeter z V.A.G 1594 C adapter set z Electrical Wiring Diagrams Test conditions z Camshaft Position (CMP) sensor -G40- installed tightly z Battery voltage must be at least 11.5 V Test sequence z Disconnect 3-pin connector from Camshaft Position (CMP) sensor -arrow-. must always be fastened to and operated from the rear seat by a Engine code AWP AWV Firing order 1-3-4-2 1-3-4-2 Spark plugs (1) , (2) VW/Audi 101 000 063 AA 101 000 063 AA Manufacturer ID NGK PFR 6 Q NGK PFR 6 Q Electrode gap max. 0.8 mm max. 0.8 mm Tightening torque 30 Nm 30 Nm (1) The up-to -date figures and the spark plug change intervals: (2) Remove and install spark plugs with 3122B and appropriate extension.
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Ignition/Glow plug system, 1.8L AWP, AWV - New Beetle
|
