Volkswagen New Beetle. Manual - part 1501





3. Snap ring

z

for Ignition Coil 1 with Power Output Stage -N70-, Ignition Coil 2 with Power Output Stage -
N127-, Ignition Coil 3 with Power Output Stage -N291-, Ignition Coil 4 with Power Output Stage -
N292-

z

Replace if damaged

4. Spark plug, 30 Nm

z

remove and install with 3122 B

z

Type and spark plug gap, see TEST DATA, SPARK PLUGS

5. Connector

z

black, 3-pin

z

Terminals of sensor and connector are gold-plated

6. 10 Nm

7. Camshaft Position (CMP) Sensor -G40-*

z

Checking, see CHECK CAMSHAFT POSITION (CMP) SENSOR

8. 25 Nm

9. Washer

z

Conical

10. Face plate

z

For Camshaft Position (CMP) Sensor -G40-

z

note position when installing

11. 20 Nm

z

Tightening torque affects function of Knock Sensor (KS)

12. Knock Sensor (KS) 1 -G61-*

z

Terminals of sensor and connector are gold-plated

z

Component location: Cylinder block, intake side

z

Checking, see CHECK KNOCK SENSORS

13. Knock Sensor (KS) 2 -G66-*

z

Terminals of sensor and connector are gold-plated

z

Component location: Cylinder block, intake side

z

Checking, see CHECK KNOCK SENSORS

14. Connector

z

2-pin

z

Terminals are gold-plated

z

Black for Knock Sensor (KS) 1 -G61-

z

Black for Knock Sensor (KS) 2 -G66-

z

Mark connector before removing

15. Ground (GND) wire

z

Do not loosen or tighten unless ignition is switched off.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



16. 10 Nm

z

Do not loosen or tighten unless ignition is switched off.

Fig. 2: Identifying Parts Of Ignition (Vehicles With Engine Code AWP, AWV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Camshaft adjustment, servicing (Vehicles with engine code AWP, AWV)

Cylinder head, removing and installing:

See CYLINDER HEAD, REMOVING AND INSTALLING

Valvetrain, servicing:

See VALVE GEAR, SERVICING

The following list pertains to Fig. 3 .

1. Double bearing cap

2. 10 Nm

3. Exhaust camshaft bearing cap

4. Exhaust camshaft

5. Intake camshaft bearing cap

6. Intake camshaft



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



7. Drive chain

z

Mark direction of travel (installation position) before removing

8. Camshaft adjuster

z

Check valves for camshaft adjustment, see VALVE FOR CAMSHAFT ADJUSTMENT,
CHECKING (VEHICLES WITH ENGINE CODE AWP, AWV)


9. 10 Nm

10. Valve -1- for camshaft adjustment -N205-*

z

only together with camshaft adjuster item 8 , replacing

z

Checking, see VALVE FOR CAMSHAFT ADJUSTMENT, CHECKING (VEHICLES WITH
ENGINE CODE AWP, AWV)


11. Seal

z

Rubber/metal seal

z

replace

12. Seal

z

replace

13. Cylinder head



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



Fig. 3: Identifying Camshaft Adjustment, Servicing (Vehicles With Engine Code AWP, AWV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Safety precautions

WARNING:

Observe the following for all installations, especially in engine
compartment due to lack of room:

z

Route lines of all types (e.g. for fuel, hydraulic, EVAP canister
system, coolant and refrigerant, brake fluid, vacuum) and electrical
wiring so that the original path is followed.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle
