Volkswagen New Beetle. Manual - part 1461





z

If the vehicle is equipped with an air conditioner, this must be switched off.

Checking function and voltage supply

z

Remove cover from fuel delivery unit.

z

Briefly operate starter.

Fuel pump must be heard to run.

z

Switch ignition off.

If the fuel pump does not run:

z

Remove cover in front of fuse holder.

z

Pull fuse No. 28 out of fuse holder.

Fig. 19: Connecting Remote Control VAG 1348/3A With Adapter Cable VAG 1348/3-2 To
Terminal 28A

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect remote control VAG 1348/3A with adapter cable VAG 1348/3-2 to terminal 28a to fuel pump
and battery positive (+).

z

Operate remote control.

NOTE:

Observe description of function of crash fuel shut-off. See CRASH FUEL SHUT-
OFF .

NOTE:

Check whether a coded radio is installed as during the forthcoming work
sequences the battery Ground strap must be disconnected. Obtain radio code
first if necessary.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



Fuel pump runs:

z

Check activation of fuel pump relay using wiring diagram:

See appropriate WIRING DIAGRAM article

Fuel pump does not run:

z

Pull 4 pin connector off flange on fuel delivery unit.

z

Connect LED test light VAG 1527 B with auxiliary cables from VAG 1594 A to outer terminals of
connector.

Fig. 20: Connecting LED Test Light VAG 1527 B With Auxiliary Cables From VAG 1594 A To
Outer Terminals Of Connector

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate remote control.

LED must light up

LED does not light up:

z

Locate and eliminate open circuit using wiring diagram:

See appropriate WIRING DIAGRAM article

LED lights up (voltage supply OK.):

z

Remove union nut with 3217 wrench.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 21: Removing Union Nut With 3217 Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check that electrical wires between flange and fuel pump are connected.

If no open circuit can be found:

z

Fuel pump malfunctioning, replace fuel delivery unit. See RULES OF CLEANLINESS .

Checking delivery rate

Test conditions

z

Voltage supply OK

z

Remote control VAG 1348/3A connected

Test sequence

z

Remove filler cap from fuel tank filler neck.

z

Pull off supply pipe/hose -1- and collect leaking fuel with a cloth.

WARNING:

Fuel system is under pressure! Before opening the system place a
cloth around the connection. Then release pressure by carefully
loosening the connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 22: Pulling Off Supply Pipe/Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect pressure gauge VAG 1318 with adapter 1318/23 and VAG 1318/17 to fuel supply hose.

Fig. 23: Connecting Pressure Gauge VAG 1318 With Adapter 1318/23 And VAG 1318/17 To Fuel
Supply Hose

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Push hose VAG 1318/1 onto adapter VAG 1318/11 on pressure gauge and hold hose in a measuring
container.

z

Open pressure gauge cut-off tap. Lever then points in throughflow direction -A-.

z

Operate remote control VAG 1348/3A and slowly close cut-off tap, until pressure gauge shows 3 bar.
From this point on do not move position of cut-off tap.

z

Empty measuring container.

z

Fuel pump delivery range is dependent upon battery voltage. Therefore, connect multimeter with adapter
cables from VAG 1594A to vehicle battery.

z

Operate remote control for 30 seconds and measure battery voltage.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)
