1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP) FUEL SUPPLY SYSTEM COMPONENTS, REMOVING AND INSTALLING z Observe safety precautions. See SAFETY PRECAUTIONS WHEN WORKING ON FUEL SUPPLY z Observe rules for cleanliness. See RULES OF CLEANLINESS . Removing and installing fuel tank with its attachments and fuel filter. See FUEL TANK WITH Observe crash fuel shut-off. See CRASH FUEL SHUT-OFF . Electronic Engine Power Control (EPC) system, checking. See ELECTRONIC ENGINE POWER Servicing parts of the Evaporative Emission (EVAP) system. See EVAPORATIVE EMISSION (EVAP) FUEL TANK WITH ATTACHMENTS AND FUEL FILTER, REMOVING AND INSTALLING 1. Sealing cap z Secured with strap from MY 2000 2. Seal z Replace if damaged 3. Securing screw 4. Tank flap unit z With rubber cup 5. Vent pipe z Black z Check securely seated NOTE: z Hose connections are secured with either spring-type or clamp-type clips. z Always replace clamp-type clips with screw-type clips. z Fuel hoses in engine compartment must only be secured with spring-type z Assembly tool VAS 5024 or hose clip pliers VAG 1921 are recommended NOTE: The following list refers to items in Fig. 1 .
