z Connect test box VAG 1598/31 to control module wiring harness. Engine Control Module is not Fig. 34: Connecting Test Box VAG 1598/31 To Control Module Wiring Harness z Check wiring between test box and connector for open circuit according to wiring diagram. Fig. 35: Identifying Connector Terminals z Contact 1 + socket 72 z Contact 2 + socket 73 z Contact 3 + socket 36 z Contact 4 + socket 35 z Contact 6 + socket 34 Vehicles with automatic transmission:
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)
|
