Volkswagen New Beetle. Manual - part 1322





Fig. 50: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and 4-pin harness connector using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 51: Identifying ECT Sensor Harness Connector Terminals 1 And 3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 1 + socket 70

z

Terminal 3 + socket 54

From MY 2000

z

Terminal 3 + socket 112

z

Terminal 4 + socket 104

z

Wire resistance: 1.5ohm maximum

z

Check wires for shorting to: one another, Ground and Battery +



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Specification: INFINITY ohm

If wiring OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

z

Erase DTC memory. See DTC MEMORY, ERASING . (Disconnecting the Engine Coolant
Temperature sensor generates a DTC).

Brake Light Switch -F63- and Brake Vacuum Vent Valve Switch for Cruise Control/Diesel Fuel Injection -F47-,
checking

The Diesel injection system senses throttle pedal travel via the Throttle Position Sensor -G79-. As with any
mechanical device, -G79- could be faulty. For reasons of safety, engine speed is regulated when the brakes are
applied. To accomplish this, the ECM requires signals from the Brake Light Switch -F- and the Brake Vacuum
Vent Valve Switch -F47-. This means that if the brakes are applied while the throttle pedal is depressed, engine
speed will immediately drop to an idle. An incorrectly adjusted switch could lead to unnecessary regulating
action.

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test sequence

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Switch ON ignition but do not start engine.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (example only):



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 52: Scan Tool Display - Brake Light Switch & Brake Vacuum Vent Valve Switch (1 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
