Volkswagen New Beetle. Manual - part 1307





Fig. 2: Exploded View Of Variable Intake Manifold
Courtesy of VOLKSWAGEN OF AMERICA, INC.

VARIABLE INTAKE MANIFOLD, DISASSEMBLING AND ASSEMBLING

z

Remove variable intake manifold.

z

Loosen connecting bolts.

z

Disconnect upper and lower part of intake manifold. Separate both parts with light blows of a rubber
headed hammer if necessary.

z

Clean contact surface.

z

Replace seal.

z

Put upper and lower part of intake manifold together and tighten all connecting bolts hand-tight.

z

Tighten all securing bolts in indicated sequence to 10 N.m.

Fig. 3: Tightening Sequence Of Upper & Lower Intake Manifold Securing Bolts

NOTE:

To avoid distortion of the variable intake manifold it must only be tightened in
the described sequence:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install variable intake manifold.

INJECTOR UNIT, SERVICING

z

Observe rules for cleanliness. See RULES FOR CLEANLINESS .

z

Always replace sealing and O-rings.

1. 20 N.m plus an additional 1/4 turn (90°)

z

Always replace

z

Note sequence when loosening and tightening. See INJECTOR UNIT, REMOVING AND
INSTALLING
 .

2. Rocker shaft

z

With rocker lever

z

Removing and installing, See INJECTOR UNIT, REMOVING AND INSTALLING .

3. Lock nut, 30 N.m

4. Adjustment screw

z

Replace when installing a new injector unit or if worn

z

Adjusting, see INJECTOR UNIT, REMOVING AND INSTALLING

5. Unit injector

z

Check ball pin for wear, replace if necessary

z

Removing and installing, see INJECTOR UNIT, REMOVING AND INSTALLING

6. O-ring

z

Replacing, See O-RINGS FOR INJECTOR UNIT, REMOVING AND INSTALLING

7. O-ring

z

Replacing, See O-RINGS FOR INJECTOR UNIT, REMOVING AND INSTALLING

8. O-ring

z

Replacing, See O-RINGS FOR INJECTOR UNIT, REMOVING AND INSTALLING

9. Heat protection gasket

z

Always replace

10. Circlip

11. Cylinder head

12. Scotch block

13. 12 N.m plus an additional 3/4 turn (270°)

z

Always replace

NOTE:

The following list refers to items in Fig. 4 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 4: Injector Unit Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

O-RINGS FOR INJECTOR UNIT, REMOVING AND INSTALLING

Special tools and equipment

z

T10056 Assembly sleeves Removing

Fig. 5: Identifying T10056 Assembly Sleeves
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove injector unit, See INJECTOR UNIT, REMOVING AND INSTALLING .

z

Carefully remove old O-rings from injector unit.

Installing

NOTE:

z

Always use assembly sleeves to install the O-rings. Otherwise the O-rings
will be damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



z

Pull heat protection gasket off together with safety ring.

z

Carefully clean contact surfaces for O-rings at injector unit.

z

Install assembly sleeve T10056/1 on injector unit onto limit stop.

Fig. 6: Installing Assembly Sleeve T10056/1 On Injector Unit Onto Limit Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully slide upper thicker O-ring on assembly sleeve and in injector unit seat.

z

Remove assembly sleeve.

z

Install assembly sleeve T10056/2 on injector unit onto limit stop.

z

Carefully slide center thinner O-ring on assembly sleeve and in injector unit seat.

z

Remove assembly sleeve.

z

Gradual introduction of O-rings without different color identification.
Observe correct application of the O-rings to the grooves: the ring
thickness decreases towards the injector.

z

Avoid rolling movements when sliding onto the O-rings. The O-rings must
not be twisted in the injector unit seat.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW
