Content .. 1240 1241 1242 1243 ..
Fig. 6: Identifying VAG 1551/1552 Scan Tool Display (2 Of 3) z Press 0, 1 and 1 buttons to select Display Group 11 z Press Q button to enter input Read measuring value block 11 --> 840 RPM 938 mbar 978 mbar 92 % Display will appear as shown z Accelerate vehicle in 3rd gear from about 1500 RPM under Wide Open Throttle. z Press VAG 1551 PRINT button at approx. 3000 RPM. Read measuring value block 11 --> 3090 RPM 1866 mbar 1917 mbar 62% Specification: 1700 to 2200 mbar (in display zone 3)
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle
|
