Volkswagen New Beetle. Manual - part 1218





Fig. 151: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1342 Oil pressure tester

z

VAG 1527 BLED test light

z

VAG 1594 A Adapter set

Function of the dynamic oil pressure warning indicator

z

When not under pressure, the oil pressure switch is open and will close when the operating pressure is
attained.

z

The oil pressure warning will be activated approx. 10 seconds after switching the ignition on.

z

Switch-in delay of oil pressure warning: approx. 3 seconds.

z

Switch-off delay of oil pressure warning: approx. 5 seconds.

See appropriate WIRING DIAGRAM article.

Checking warning lamp

After switching on the ignition without engine started, the oil pressure warning lamp in instrument cluster must
light for approx. 3 seconds and then go out. The test will be terminated if the engine is running.

Criteria for warning

Switching on the optical oil pressure warning (the oil pressure warning lamp flashes) and the buzzer sounding
three times for the acoustical warning will occur under one of the following conditions:

z

"Ignition on," engine stationary, oil pressure switch closed

NOTE:

Functional check and servicing the optical and acoustic oil pressure
warning:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Engine speed above 1500 RPM, oil pressure switch open

Test conditions

z

Engine oil level OK. See PART II

z

Oil Pressure Warning Lamp -K3- must light up for approx. 3 seconds when ignition is switched on

z

Engine oil temperature at least 80° C (radiator fan must have run once)

Test sequence

z

Remove Oil Pressure Switch -F1- and screw into tester.

Fig. 152: Removing Oil Pressure Switch -F1- And Screwing Into Tester
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Screw tester into oil filter bracket in place of oil pressure switch.

z

Connect brown wire of tester to Ground (-).

z

Connect LED test light VAG 1527 B using aux. cables from VAG 1594 A to battery positive (+) and oil

NOTE:

z

If the oil pressure switch is closed, the warning lamp will remain
switched on if the engine speed is above 5000 RPM. The warning
lamp will be switched off again if the engine speed is below 5000
RPM.

z

If the oil pressure switch is open for 0.3-3.0 seconds when the engine
speed is above 1500 RPM, it will be stored in the combi-processor in
the instrument cluster. If this condition occurs three times when the
engine is running, the oil pressure warning will be activated and will
not be cancelled even below 1500 RPM. The oil pressure warning will
be cancelled when the oil pressure switch is closed for longer than 5
seconds at an engine speed above 1500 RPM, or when the ignition is
switched off.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



pressure switch.

LED must not light up.

z

If LED lights up, replace 1.4 bar Oil Pressure Switch -F1-.

When the LED does not light up:

z

Start engine and run at idling speed:

At 1.2-1.6 bar LED must light up, otherwise replace oil pressure switch.

z

Check oil pressure at different RPMs:

z

Idle: at least 2.0 bar

z

2000 RPM: 2.7 to 4.5 bar

z

Above 2000 RPM: maximum 7.0 bar

If the specifications are not obtained:

z

Repair mechanical damage (e.g. bearing damage).

z

Replace oil filter bracket with pressure relief valve (see OIL PAN, REMOVING AND INSTALLING ,
item 23) or replace oil pump (see PART II , item 21).

At higher engine speeds the oil pressure must not exceed 7.0 bar.

If the specification is exceeded:

z

Check oil galleys.

z

If necessary, replace oil filter bracket with pressure relief valve. See OIL PAN, REMOVING AND
INSTALLING
 , item 23.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



1998-2004 ENGINE

Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)

TURBOCHARGER, G-CHARGER

CHARGE AIR SYSTEM WITH TURBOCHARGER

Removing and installing turbocharger with attachments. See TURBOCHARGER WITH ATTACHMENTS,
REMOVING AND INSTALLING
 .

Removing and installing parts of charge air cooler. See CHARGE AIR COOLING COMPONENTS,
REMOVING AND INSTALLING
 .

Observe rules of cleanliness. See RULES OF CLEANLINESS .

Observe safety precautions. See SAFETY PRECAUTIONS .

Checking charge air pressure system. See CHARGE AIR PRESSURE SYSTEM, CHECKING .

Turbocharger with attachments, removing and installing (Part I)

1. 40 N.m

z

Coat threads with G 052 112 A3

2. Seal

z

Always replace

3. 10 N.m

z

Must not be loosened

4. Pressure unit

z

For charge pressure regulator valve in turbocharger

z

Checking charge pressure regulation. See CHARGE AIR PRESSURE SYSTEM, CHECKING

z

Can only be replaced in conjunction with turbocharger

NOTE:

z

All hose connections are secured with clamps.

z

Charge air system must be free of leaks.

z

Always replace self-locking nuts.

z

Charge air pressure hose and all the respective connections must be free
of grease etc. before installing.

z

Assembly tool VAS 5024 or hose clip pliers VAG 1921 are recommended
for installing spring-type clips.

NOTE:

The following list refers to items in Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)
