z

Disassembling and assembling. See PART II

10. 15 N.m + 1/4 turn (90°) further

z

Always replace

11. Oil cooler

z

Coat contact area to flange, outside the seal, with AMV188 100 02

z

Ensure clearance to adjacent components

z

Note. See ENGINE, DISASSEMBLING AND ASSEMBLING

12. 25 N.m

13. Oil filter

z

Loosen with strap wrench

z

Tighten by hand

z

Note instructions on filter when installing

14. Gasket

z

Always replace

15. 10 N.m

16. Engine speed sender

z

Checking:

See GENERAL INFORMATION FOR ON BOARD DIAGNOSTIC (OBD)

17. Connection

18. 15 N.m

19. O-Ring

z

Always replace

20. Coolant thermostat

z

Checking: heat-up thermostat in water

z

Opening commences approx. 86°C

z

Opening lift min. 7 mm

z

Removing and installing. See THERMOSTAT, REMOVING AND INSTALLING

z

Observe installation position. See THERMOSTAT, REMOVING AND INSTALLING

z

Checking: heat-up thermostat in water

21. 45 N.m

22. Compact bracket

z

For ribbed belt tensioning roller, alternator, power steering pump and air conditioning compressor

23. Right engine bracket

Ribbed belt tensioner, removing and installing

Special Tools And Equipment



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

3090 Connecting rod support

Fig. 27: Identifying 3090 Connecting Rod Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing ribbed belt

z

Mark direction of rotation of ribbed belt.

z

To loosen ribbed belt turn tensioning element in direction of arrow.

Fig. 28: Loosening Ribbed Belt By Turning Tensioning Element In Direction Of Arrow
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lock tensioning device with 3090 Connecting rod support.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 29: Identifying Lock Tensioning Device With 3090 Connecting Rod Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove or install ribbed belt.

z

Remove insulation tray.

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Remove or install ribbed belt.

z

Start engine and check belt running.

Ribbed belt routing

Belt drive without air conditioning compressor

NOTE:

When installing ribbed belts ensure the belt seats correctly in the belt
pulley.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 30: Identifying Belt Drive Without Air Conditioning Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Belt drive with air conditioning compressor

Fig. 31: Identifying Belt Drive With Air Conditioning Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Toothed belt, removing, installing and tensioning

Special tools, workshop equipment, test and measuring appliances and aux. items required

z

10-222A Engine support bracket with 10-222A/8 adapter

z

3180 Retainer (for turbocharged engines)

z

T10092 Tensioning bolt

NOTE:

Engines with an air conditioning compressor are equipped with a double ribbed
belt.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
