Volkswagen New Beetle. Manual - part 1106





Fig. 116: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove engine cover.

z

Remove toothed belt guard (upper part).

z

Set camshaft sprocket to TDC No. 1 cylinder by turning crankshaft. Mark on camshaft sprocket must
align with mark on cylinder head cover.

Fig. 117: Aligning Mark On Camshaft Sprocket With Mark On Cylinder Head Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove cylinder head cover.

z

Take toothed belt off camshaft toothed belt sprocket. See REMOVING .

z

Turn crankshaft back slightly.

z

Remove camshaft sprocket. When loosening camshaft sprocket bolt counter-hold with 3036.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Remove woodruff key from camshaft.

z

Remove Camshaft Position (CMP) sensor housing.

z

Remove washer and hood for Camshaft Position (CMP) sensor.

z

Clean drive chain and camshaft chain sprocket in area of arrows on bearing caps and mark installation
position with a colored mark.

Fig. 118: Cleaning Drive Chain And Camshaft Chain Sprocket In Area Of Arrows On Bearing
Caps

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Secure chain tensioner with retainer for chain tensioner 3366.

Fig. 119: Securing Chain Tensioner With Retainer For Chain Tensioner 3366
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

z

Do not mark chain with a punched mark, notch or similar.

z

The distance between both arrows or the colored marks equals 16
rollers on the drive chain.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Remove intake and exhaust camshafts 3rd and 5th bearing caps.

Fig. 120: Identifying Intake And Exhaust Camshaft Bearing Cap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove double bearing cap.

z

Remove both bearing caps at chain sprockets on intake and exhaust camshafts.

z

Remove chain tensioner securing bolts.

z

Remove intake and exhaust camshaft 2nd and 4th bearing caps using alternate and cross-over sequence.

z

Remove chain tensioner for intake and exhaust camshafts and retainer for chain tensioner 3366.

Installing

z

Install drive chain onto both camshafts relevant to colored markings.

NOTE:

Hydraulic chain tensioner can be damaged if chain tensioner retainer is
overtightened.

NOTE:

z

When installing the camshafts the cams for No. 1 Cyl. must point upward.

z

When installing the bearing caps, ensure that the cap markings can be
read from the inlet side of the cylinder head.

NOTE:

z

When using a new timing chain, the distance between notches -A-
and -B- at the camshaft equals 16 rollers on the drive chain.

z

The figure shows where on the sprockets the 1st and 16th rollers
must be placed.

z

Notch -A- is slightly offset toward inside to chain roller 1.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Replace rubber/metal seal for camshaft adjuster or chain tensioner and lightly coat hatched area with
sealant D 454 300 A2.

Fig. 122: Identifying Lightly Coated Hatched Area With Sealant D 454 300 A2
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Place chain onto camshaft gears as follows:

z

Slide camshaft adjuster or chain tensioner between drive chain.

z

Oil running surfaces of both camshafts.

z

Place camshafts with drive chain and camshaft adjuster or chain tensioner in cylinder head.

z

Tighten camshaft adjuster or chain tensioner to 10 N.m (take note of dowel sleeves).

z

Tighten intake and exhaust camshaft 2nd and 4th bearing caps using alternate and cross-over sequence to
10 N.m (take note of dowel sleeves).

Fig. 121: Identifying Distance Between Notches -A- And -B- At Camshaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
