Volkswagen New Beetle. Manual - part 1103





Fig. 100: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing oil seal on camshaft sprocket

z

Remove seal on Camshaft Position (CMP) sensor. See OIL SEAL ON CAMSHAFT POSITION
(CMP) SENSOR, REMOVING
 .

z

Remove toothed belt guard (upper part).

z

Set camshaft sprocket to TDC No. 1 cylinder by turning crankshaft. Mark on camshaft sprocket must
align with mark on cylinder head cover.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 101: Aligning Mark On Camshaft Sprocket With Mark On Cylinder Head Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove cylinder head cover.

z

Release tensioner and remove toothed belt from camshaft sprocket.

z

Turn crankshaft back slightly.

z

Remove camshaft sprocket. When loosening camshaft sprocket bolt counter-hold with 3036.

z

Remove woodruff key from camshaft.

z

Screw camshaft sprocket securing bolt -arrow- into camshaft onto stop by hand, to guide seal extractor.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 102: Screwing Camshaft Sprocket Securing Bolt Into Camshaft Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew inner part of oil seal extractor 2085 two turns (approx. 3 mm) out of outer part and lock in
position with knurled screw.

z

Lubricate threaded head of oil seal extractor, place it in position and exerting firm pressure screw it into
oil seal as far as possible.

z

Loosen knurled screw and turn inner part of extractor against camshaft until oil seal has been extracted.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 103: Removing Oil Seal Using Special Tool 2085
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Before installing, remove oil remains from crankshaft journal with a clean cloth.

z

Install guide sleeve 3241/2 onto camshaft journal.

NOTE:

Gradual introduction of PTFE (Teflon) oil seal (identifying characteristics: no
annular spring, sealing lip wider). The sealing lip of this oil ring must not be
oiled or lubricated. A plain encased seal of older construction (with annular
spring) may be replaced with a PTFE oil seal, but not vice versa.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
