Volkswagen New Beetle. Manual - part 1080





Fig. 157: Applying Silicone Sealing Compound To Sump Sealing Surface
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Apply silicone sealing compound, as shown, to clean sump sealing surface. Sealing compound bead must
be:

z

2...3 mm thick (for engine code BEV: 1...2 mm thick)

z

and run on inside of bolt holes (arrows).

z

Carefully apply sealing compound bead in areas marked by arrows. (illustration shows position of sealant
bead on cylinder block).

NOTE:

The sealing compound bead must not be thicker, otherwise excess sealing
compound will enter the sump and may block the oil suction pipe strainer.

NOTE:

z

When installing the sump on an engine which is removed from the
vehicle, ensure that the sump is flush with the cylinder block on the
flywheel end.

z

The sealant must be allowed to cure for approx. 30 minutes after
installing the sump. After this time the engine may be filled with
engine oil.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 158: Locating Areas For Applying Sealing Compound Bead
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install sump immediately and tighten bolts as follows:

1. Tighten all sump/cylinder block bolts lightly using diagonal sequence.

2. Tighten three sump/transmission bolts lightly.

3. Tighten all sump/cylinder block bolts lightly using diagonal sequence again.

4. Tighten sump/transmission bolts to 45 N.m.

5. Tighten all sump/cylinder block bolts to 15 N.m using diagonal sequence.

Engine code BEV (Oil sump lower part protection)

z

Apply silicone sealing compound D 176 501 A1, as shown, to clean sump sealing surface.

NOTE:

z

Note the use-by date of the sealant.

z

The sump must be installed within 5 minutes of applying silicone sealing
compound.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 159: Locating Areas For Applying Silicone Sealing Compound (Engine Code BEV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Sealing compound bead must be A = 1...2 mm. thick.

z

and run on inside of bolt holes (arrows).

z

Install spreader rivets -3- in oil sump protection -4-. See Fig. 138

NOTE:

z

The sealing compound bead must not be thicker, otherwise
excess sealing compound will enter the sump and may block
the oil suction pipe strainer.

z

When installing the sump on an engine which is removed from
the vehicle, ensure that the sump is flush with cylinder block on
the flywheel end.

z

The sealant must be allowed to cure for approx. 30 minutes after
installing the sump. After this time the engine may be filled with
engine oil.

NOTE:

Models with oil sump protection

z

Check condition of the rubber grommets located in the cylinder block for
spreader rivets, before installing the oil sump protection.

z

Before tightening bolts, clean the threads and apply D 000 600 A2.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 160: Installing Oil Sump Protection
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten bolts -2- to 37 N.m.

Continuation for all models

The rest of the assembly is basically in reverse order to the disassembly sequence.

Oil pressure and oil pressure switch, checking

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1342 Oil pressure tester

z

V.A.G 1527 B Diode test lamp

z

V.A.G 1594 A Adapter set



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
