2. Remove driver-side sound insulator and knee bolster. Remove Connector Position Assurance (CPA) clip and disconnect driver-side air bag Yellow SRS 2-pin connector at base of steering column. See Fig. 20 . Activating System (Hombre) 1. Ensure ignition switch is in LOCK position, and ignition key is removed. Reconnect Yellow SRS 2-pin connectors and install CPA clips. Install knee bolster, sound insulator, trim panels and glove box. 2. Staying well away from air bag modules, turn ignition switch to RUN position. Ensure AIR BAG warning light flashes 7 times, and then turns off. If AIR BAG warning light does not operate as described, Fig. 20: Disconnecting Driver-Side Yellow 2-Pin SRS Connector (Hombre) Disabling System (1997 Rodeo) 1. Turn ignition switch to LOCK position and remove key. Wait 15 SECONDS before servicing vehicle. Remove SRS fuses (SRS-1 and SRS-2) from instrument panel fuse block. NOTE: When AIR BAG fuse is removed and ignition switch is in ON position, AIR BAG
1997 Lexus SC 300 GENERAL INFORMATION Air Bag Deactivation Procedures
