❑ 4 Nm 15 - Left gas discharge bulb control unit -J343- / right gas discharge bulb control unit -J344- ❑ Not capable of self-diagnosis 16 - Bolt ❑ 2 Nm 17 - Left headlight main beam bulb -M30- / right headlight main beam bulb -M32- ❑ Bulb: H7U 12 V/55 W 18 - Front left turn signal bulb -M5- / front right turn signal bulb -M7- ❑ Bulb: H2 WLL 12 V/21 W 19 - Left side light bulb -M1- / right side light bulb -M3- ❑ Bulb: W 12 V/5 W 20 - Cover cap 3.3 Removing and installing headlight Removing and installing headlights . Observe safety notes for gas discharge bulbs . 3.4 Adjusting headlight installation position Adjusting headlight installation position . 3.5 Renewing bulbs 3.5.1 Renewing gas discharge bulb Note The diagrams show renewal of left gas discharge (xenon) bulb - L13- for the left headlight. Caution ♦ Switch off ignition and all electrical consumers. Removing 262 |
