Removing and installing joint-free wiper blades Note ♦ Driver and front passenger wiper blades must not be inter‐ changed during installation. ♦ Joint-free wiper blades are very flexible. To lift the wiper blades off the windscreen, touch them only in the area in which the wiper blades are attached to the wipers. ♦ To remove the wiper blades, the wiper arms should be placed in the „service/winter position“. The „service/winter position“ is activated within 10 seconds after ignition is switched off by pressing the windscreen wiper lever in position „tip wipe“. Removing screen wiper lever to „flick wipe“ position 10 seconds after ignition has been switched off. – Lift up wiper arm. 1.7 Removing and installing rain and light sensor -G397- If an intact rain and light sensor -G397- has to be removed from its retaining plate on the windscreen (replacement of windscreen), it can be subsequently reinstalled. If the front windscreen is cracked in the area of the rain and light sensor -G397- before removal, the rain and light sensor -G397- cannot be used again. location until reinstallation and ensure the silicone contact pad is not soiled. Caution ♦ Switch off ignition and all electrical consumers. gr. 68 . 190 |
