Description of Vehicle Diagnosis, Testing and Information Systems   . . . . . . . . . . . . . . . . . . 89

1.2

Connect the Vehicle Diagnostic Tester    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

1.3

Vehicle Diagnostic Tester, Connecting, Golf MY 1998 through 2003   . . . . . . . . . . . . . . . . 90

2

Connectors   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

2.1

Wiring Harnesses and Connectors, Repairing   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

2.2

Vehicle Electrical System, General Repair Information   . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

2.3

Wiring Harnesses, Repairing   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

3

Connector Housings, Releasing and Disassembling   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

3.1

Connector Housings, Releasing and Disassembling   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

3.2

Connector Housings and Connectors, Repairing   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

4

Contact Surfaces, Cleaning   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

4.1

Contact Surface Cleaning Set VAS6410    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

5

Antenna Wires, Repairing   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

5.1

General Information   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

5.2

Overview - Antenna Wiring   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

5.3

New Antenna Wire, Installing   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

6

Fiber-Optic Cable   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

6.1

Fiber-Optic Cables, Repairing   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

6.2

Fiber-Optic Cable, Assembling   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

6.3

Fiber-Optic Cable, Disconnecting from Wiring Harness Connector   . . . . . . . . . . . . . . . . . . 130

7

Heated Oxygen Sensor, Replacing   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

7.1

Heated Oxygen Sensor, Replacing, 4-Pin Universal Oxygen Sensor   . . . . . . . . . . . . . . . . 131

7.2

Heated Oxygen Sensor, Replacing, 6-Pin Universal Oxygen Sensor   . . . . . . . . . . . . . . . . 131

7.3

Oxygen Sensor Unit Protective Pipes   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

8

Special Tools   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

9

Revision History   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Beetle 2012 ➤ , Golf 2015 ➤ , Golf Variant 2007 ➤ , Golf Variant 2010 ➤ ...

ii

    Contents

1

Battery

⇒ “1.1 Battery Types”, page 1
⇒ “1.2 Battery General Information”, page 3
⇒ “1.3 Warnings and Safety Precautions”, page 3
⇒ “1.4 Battery Post/Terminal”, page 6

1.1

Battery Types

⇒ “1.1.1 Battery with Visual Indicator, Standard ”, page 1
⇒ “1.1.2  AGM Battery”, page 2
⇒ “1.1.3 EFB Battery with Visual Indicator, Enhanced ”,

page 2

1.1.1

Battery with Visual Indicator, »Stand‐

ard«

Maintenance-free Battery - A- with fluid electrolyte (wet battery)

Caution

Do not remove any of the labels on the battery and do not add

distilled water. Perform only a visual inspection. Note the chap‐

ter

on

battery

testing.

Refer

to

⇒ “2 Battery, Checking”, page 7

 .

WARNING

Do not check or charge a Battery - A- when the visual indicator

has »no color or is bright yellow«. Jump starting must not be

used!
There is a risk of explosion during testing, charging or jump

starting.
These Batteries - A- must be replaced.

This Battery - A- has a color display (visual indicator). The colors

in the visual indicator show the Battery - A- charge and electrolyte

level.
Visual indicator, checking. Refer to

⇒ “2.3 Color Display in Battery Cover, Checking, Visual Indicator”,

page 10

 .

Using approved battery chargers, all tests can be performed on

these batteries. Observe the settings on the battery charger. Re‐

fer to

⇒ “2 Battery, Checking”, page 7

 .

Beetle 2012 ➤ , Golf 2015 ➤ , Golf Variant 2007 ➤ , Golf Variant 2010 ➤ ...

1. Battery

1

AGM Battery

Maintenance-free Battery - A- with fixed electrolyte (AGM battery)

Caution

Do not remove any of the labels on the battery and do not add

distilled water. Perform only a visual inspection. Note the chap‐

ter

on

battery

testing.

Refer

to

⇒ “2 Battery, Checking”, page 7

 .

Lead-acid battery, where the electrolyte is fixed in an absorbent

glass mat (AGM). The Battery - A- is closed and equipped with

breather valves.
“AGM” is the English abbreviation for »absorbent glass mat«.
These Batteries - A- cannot have a visual indicator due to the fixed

electrolyte. AGM is on the Battery - A- to identify it.
When replacing an AGM battery, another AGM battery must be

installed.
Using approved battery chargers, all tests can be performed on

AGM batteries. Observe the settings on the battery charger. Refer

to

⇒ “2 Battery, Checking”, page 7

 .

1.1.3

EFB Battery with Visual Indicator, »En‐

hanced«

Maintenance-free Battery - A- with fluid electrolyte (wet battery)

Caution

Do not remove any of the labels on the battery and do not add

distilled water. Perform only a visual inspection. Note the chap‐

ter

on

battery

testing.

Refer

to

⇒ “2 Battery, Checking”, page 7

 .

WARNING

Do not check or charge a Battery - A- when the visual indicator

has »no color or is bright yellow«. Jump starting must not be

used!
There is a risk of explosion during testing, charging or jump

starting.
These Batteries - A- must be replaced.

The Battery - A- is installed in certain Stop/Start vehicles due to

special requirements. “EFB” is written on the battery cover to

identify this battery.
“EFB” stands for »Enhanced Flooded Battery« (enhanced wet

battery).
An EFB battery may only be replaced with another EFB battery.
An EFB battery has a visual indicator for checking the battery

electrolyte level.

Beetle 2012 ➤ , Golf 2015 ➤ , Golf Variant 2007 ➤ , Golf Variant 2010 ➤ ...

2

EFB batteries are being installed in smaller gasoline engines with

the Stop/Start system and a manual transmission from 05/2011.

Visual indicator, checking. Refer to

⇒ “2.3 Color Display in Battery Cover, Checking, Visual Indicator”,

page 10

 .

Using approved battery chargers, all tests can be performed on

EFB batteries. Observe the settings on the battery charger. Refer

to

⇒ “2 Battery, Checking”, page 7

 .

1.2

Battery General Information

To guarantee a long service life, the Battery - A- must be checked,

serviced and maintained as described in this manual.
The Battery - A- supplies the power to start the engine. The Bat‐

tery - A- also acts as a power reserve for the entire vehicle

electrical system.

Note

Refer to ⇒ Self Study Program  No.  234 ; Battery .

Caution

In order to prevent damage to the Battery - A- or vehicle, ob‐

serve  the  battery  type  information.  Refer  to

⇒ “1.1 Battery Types”, page 1

 .

WARNING

Risk of injury. Follow all warning messages and safety pre‐

cautions.

Refer

to

⇒ “1.3 Warnings and Safety Precautions”, page 3

 .

1.3

Warnings and Safety Precautions

⇒ “1.3.1 Dangers When Working with Batteries”, page 3
⇒ “1.3.2 Battery Safety Label”, page 5
⇒ “1.3.3 Working on Airbag System”, page 5

1.3.1

Dangers When Working with Batteries

Recognizing and Preventing Risks
Batteries - A- present risks. Read the warnings on the Battery -

A- label, in the Owner's Manual and in ELSA to prevent these

risks.

Beetle 2012 ➤ , Golf 2015 ➤ , Golf Variant 2007 ➤ , Golf Variant 2010 ➤ ...

1. Battery

3
