Volkswagen Golf / Golf Plus. Manual - part 299





- vehicles with dual clutch gearbox

6-speed dual clutch gearbox: If the engine or gearbox has to be

removed during repairs, check needle bearing in crankshaft. If it

is damaged or tarnished blue, it must be renewed.
– If it is not damaged, lightly grease with high-temperature

grease -G052133A2- .

7-speed dual clutch gearbox: Always renew needle bearing when

removing engine or gearbox.
6-speed dual clutch gearbox

This gearbox can be identified by the gearbox oil cooler
Special tools, testers, measuring instruments and auxiliary items

required

4-cylinder diesel engine (1.9 l engine) - Edition 01.2009

34

     Rep. Gr.13 - Crankshaft group



4-cylinder diesel engine (1.9 l engine) - Edition 01.2009

3. Crankshaft

35



7-speed dual clutch gearbox
No gearbox oil cooler is installed.
Always renew needle bearing when removing engine or gearbox.
Special tools, testers, measuring instruments and auxiliary items

required

4-cylinder diesel engine (1.9 l engine) - Edition 01.2009

36

     Rep. Gr.13 - Crankshaft group



Procedure
• Gearbox is unscrewed from engine.
Pulling needle bearing out:
– Pull out using commercially available puller -A-, e.g. Kukko

21/2 and Kukko 22/1.

Installing

4-cylinder diesel engine (1.9 l engine) - Edition 01.2009

3. Crankshaft

37
