4-6. Driving tips
323
WARNING
■Off-road driving precautions
Always observe the following precautions to minimize the risk of death, seri-
ous injury or damage to your vehicle:
● Drive carefully when off the road. Do not take unnecessary risks by driving
in dangerous places.
● Do not grip the steering wheel spokes when driving off-road. A bad bump
could jerk the wheel and injure your hands. Keep both hands and espe-
cially your thumbs on the outside of the rim.
● Always check your brakes for effectiveness immediately after driving in
sand, mud, water or snow.
● After driving through tall grass, mud, rock, sand, rivers, etc., check that
there is no grass, bush, paper, rags, stone, sand, etc. adhering or trapped
on the underbody. Clear off any such matter from the underbody. If the
vehicle is used with these materials trapped or adhering to the underbody,
a breakdown or fire could occur.
4
● When driving off-road or in rugged terrain, do not drive at excessive
speeds, jump, make sharp turns, strike objects, etc. This may cause loss
of control or vehicle rollover causing death or serious injury. You are also
risking expensive damage to your vehicle’s suspension and chassis.
RAV4_OM_OM0R012U_(U)
324
4-6. Driving tips
NOTICE
■ To prevent the water damage
Take all necessary safety measures to ensure that water damage to the
engine or other components does not occur.
● Water entering the engine air intake will cause severe engine damage.
● Water entering the automatic transmission will cause deterioration in shift
quality, locking up of your transmission accompanied by vibration, and ulti-
mately damage.
● Water can wash the grease from wheel bearings, causing rusting and pre-
mature failure, and may also enter the differentials, transmission and
transfer case (AWD models), reducing the gear oil’s lubricating qualities.
■ When you drive through water
If driving through water, such as when crossing shallow streams, first check
the depth of the water and the bottom of the riverbed for firmness. Drive
slowly and avoid deep water.
■ Inspection after off-road driving
● Sand and mud that has accumulated around brake drums and around
brake discs may affect braking efficiency and may damage brake system
components.
● Always perform a maintenance inspection after each day of off-road driv-
ing that has taken you through rough terrain, sand, mud, or water. For
scheduled maintenance information, refer to the “Scheduled Maintenance
Guide” or “Owner’s Manual Supplement”.
RAV4_OM_OM0R012U_(U)
4-6. Driving tips
325
4
RAV4_OM_OM0R012U_(U)
326
Audio system
5
5-1.
Basic Operations
5-8. Bluetooth® Audio
Audio system types
328
Operating a Bluetooth®
Using the steering wheel
enabled portable
audio switches
331
player
380
AUX port/USB port
334
5-9. Bluetooth® Phone
5-2.
Using the audio system
Making a phone call
383
Optimal use of the
When receiving a
audio system
336
phone call
385
Speaking on the phone
386
5-3.
Using the radio
Radio operation
338
5-10.Bluetooth®
Bluetooth®
388
5-4.
Playing an audio CD and
MP3/WMA discs
5-11.Using the audio system
CD player operation
340
(Entune Audio)
Audio system
5-5.
Using an external device
(Entune Audio)
392
Listening to an iPod
350
5-12. Basic Operations
Listening to USB
memory device
356
Audio system operations
(Entune Audio)
394
Using the AUX port
362
Steering wheel audio
5-6.
Using Bluetooth® devices
switches
396
Bluetooth® audio/
AUX port/USB port
397
phone
363
Basic audio operations
398
Using the steering
wheel switches
368
5-13.Setup
Register a Bluetooth®
Setup menu
400
device
369
General settings
401
5-7.
“SETUP” menu
Audio settings
403
Using the “SETUP” menu
Display settings
404
(“Bluetooth*” menu)
370
Voice settings
406
Using the “SETUP” menu
5-14. Using the audio system
(“PHONE” menu)
375
Selecting the audio
source
407
List screen operation
408
Optimal use of the audio
system
410
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
RAV4_OM_OM0R012U_(U)
327
Audio system
5
5-15. Using the radio
5-19.Bluetooth® Audio
Radio operation
411
Listening to Bluetooth®
Audio
443
5-16. Playing an audio CD and
MP3/WMA/AAC discs
5-20.Bluetooth® Phone
CD player operation
413
Using a Bluetooth®
CD player and disc
Phone
445
information
414
Making a call
447
5-17. Using an external device
Receiving a call
450
iPod player operation
420
Speaking on the phone
451
USB memory device
Bluetooth® phone
player operation
425
message function
454
Using the AUX port
430
Using the steering
wheel switches
459
5-18. Connecting Bluetooth®
Bluetooth® phone
Preparations to
settings
460
use wireless
communication
431
5-21.Phonebook
Registering a Bluetooth®
Contact/Call History
audio player for the
Settings
462
first time
434
5-22.Bluetooth®
Registering a Bluetooth®
What to do if...
phone for the
(Troubleshooting)
472
first time
435
Bluetooth®
476
Registering a Bluetooth®
5-23. Other function
device
436
Voice command
Connecting a Bluetooth®
system
482
device
438
Displaying a Bluetooth®
device details
440
Detailed Bluetooth®
settings
441
RAV4_OM_OM0R012U_(U)
328
5-1. Basic Operations
Audio system types
Vehicles with Entune Premium Audio with Navigation
Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
Vehicles with Entune Audio Plus
Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
Vehicles with Entune Audio
→P. 392
RAV4_OM_OM0R012U_(U)
5-1. Basic Operations
329
Vehicles without Entune Premium Audio with Navigation or Entune
Audio Plus or Entune Audio
CD player with AM/FM radio
Changing language setting
5
1
Press the “SETUP” button.
2
Turn the “TUNE•SCROLL” knob to select “Language”.
3
Press the knob.
4
Turn the knob as corresponds to the desired language.
“English”, “Español”, or “Français” can be selected.
Press the knob or
(SAVE) to return to the setup menu.
■Using cellular phones
Interference may be heard through the audio system’s speakers if a cellular
phone is being used inside or close to the vehicle while the audio system is
operating.
RAV4_OM_OM0R012U_(U)
330
5-1. Basic Operations
WARNING
■ Certification for the disc player
● Part 15 of the FCC Rules
FCC Warning:
Changes or modifications not expressly approved by the party responsi-
ble for compliance could void the user’s authority to operate the equip-
ment.
● Laser products
• Do not take this unit apart or attempt to make any changes yourself.
This is an intricate unit that uses a laser pickup to retrieve information
from the surface of compact discs. The laser is carefully shielded so
that its rays remain inside the cabinet. Therefore, never try to disassem-
ble the player or alter any of its parts since you may be exposed to laser
rays and dangerous voltages.
• This product utilizes a laser.
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
NOTICE
■ To prevent battery discharge
Do not leave the audio system on longer than necessary with the engine is
stopped.
■ To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.
RAV4_OM_OM0R012U_(U)
5-1. Basic Operations
331
Using the steering wheel audio switches
Some audio features can be controlled using the switches on
the steering wheel.
Operation may differ depending on the type of audio system or
navigation system. For details, refer to the manual provided with
the audio system or navigation system.
1
Volume
2
Radio mode:
Selects a radio station
CD mode:
Selects a track and file (MP3
and WMA)
Bluetooth® audio mode:
Selects a track and album
5
iPod mode:
Selects a song
USB memory mode:
Selects a file and folder
Power on, select audio source
3
RAV4_OM_OM0R012U_(U)
332
5-1. Basic Operations
Turning on the power
Press the “MODE” switch when the audio system is turned off.
Changing the audio source
Press the “MODE” switch when the audio system is turned on. The
audio source changes as follows each time the button is pressed. If a
mode cannot be used, it will be skipped.
AM→FM1→FM2→CD mode→iPod or USB memory→
Bluetooth® audio→AUX
Adjusting the volume
Press the “+” switch to increase the volume and the “-” switch to
decrease the volume.
Hold down the switch to continue increasing or decreasing the volume.
Silencing a sound
Press and hold the “MODE” switch.
To cancel, press and hold the switch again.
Selecting a radio station
1
Press the “MODE” switch to select the radio mode.
2
Press the “∧” or “∨” switch to select a preset station.
To scan for receivable stations, press and hold the switch until you hear a
beep.
RAV4_OM_OM0R012U_(U)
5-1. Basic Operations
333
Selecting a track/file or song
1
Press the “MODE” switch to select the CD, Bluetooth® audio, iPod
or USB memory mode.
2
Press the “∧” or “∨” switch to select the desired track/file or song.
Selecting an album
1
Press the “MODE” switch to select Bluetooth® audio mode.
2
Press and hold the “∧” or “∨” switch until you hear a beep.
Selecting a folder (MP3 and WMA or USB memory)
1
Press the “MODE” switch to select CD or USB memory mode.
2
Press and hold the “∧” or “∨” switch until you hear a beep.
WARNING
■ To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
5
RAV4_OM_OM0R012U_(U)
334
5-1. Basic Operations
AUX port/USB port
Connect an iPod, USB memory device or portable audio player
to the AUX port/USB port as indicated below. Press the “MEDIA”
button to select “iPod”, “USB” or “AUX”.
Connecting using the AUX port/USB port
■ iPod
Open the cover and connect an
iPod using an iPod cable.
Turn on the
power of the iPod if
it is not turned on.
■ USB memory
Open the cover and connect the USB memory device.
Turn on the power of the USB memory device if it is not turned on.
■ Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
■ AUX port
Do not connect a device or operate the device controls.
Silencing a sound
Press
(MUTE).
To cancel, press
(UNMUTE).
■ Operating portable audio devices connected to the audio system
The volume can be adjusted using the vehicle’s audio controls. All other
adjustments must be made on the portable audio device itself.
■ When using a portable audio device connected to the power outlet
Noise may occur during playback. Use the power source of the portable
audio device.
RAV4_OM_OM0R012U_(U)
5-1. Basic Operations
335
WARNING
■While driving
Do not connect a device or operate the device controls.
5
RAV4_OM_OM0R012U_(U)
336
5-2. Using the audio system
Optimal use of the audio system∗
The sound quality, volume balance and ASL settings can be
adjusted.
1
Displays the “SETUP” menu
2
Changes the following settings
• Sound quality and volume
balance
The sound quality and balance
setting can be changed to pro-
duce the best sound.
• Automatic sound levelizer
→P. 337
• Language
→P. 329
3
Selecting the mode
Using the audio control function
■ Changing sound quality modes
1
Press the “SETUP” button.
2
Turn the “TUNE•SCROLL” knob to select “Sound Setting”.
3
Press the knob.
4
Turn the knob as corresponds to the desired mode.
“BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL” can be selected.
5
Press the knob.
∗: If equipped
RAV4_OM_OM0R012U_(U)
5-2. Using the audio system
337
■ Adjusting sound quality
Turning the “TUNE•SCROLL” knob adjusts the level.
Sound
Mode
Turn to the
Turn to the
Level
quality mode
displayed
left
right
Bass*
“BASS”
-5 to 5
Low
High
Treble*
“TREBLE”
-5 to 5
Front/rear volume
“FADER”
F7 to R7
Shifts to rear
Shifts to front
balance
Left/right
volume
“BALANCE”
L7 to R7
Shifts to left
Shifts to right
balance
*: The sound quality level is adjusted individually in each audio mode.
Press the knob or
(SAVE) to return to the sound setting menu.
■ Adjusting the Automatic Sound Levelizer (ASL)
When ASL is selected, turn the “TUNE•SCROLL” knob to change
the amount of ASL.
5
“LOW”, “MID”, “HIGH”, or “OFF” can be selected.
ASL automatically adjusts the volume and tone quality according to
vehicle speed.
Press the knob or
(SAVE) to return to the sound setting menu.
RAV4_OM_OM0R012U_(U)
338
5-3. Using the radio
Radio operation∗
1
Power
5
AM/FM mode button
2
Volume
6
Station selectors
3
Adjusting the frequency
7
Seeking the frequency
4
Scanning for receivable sta-
8
Displaying text message
tions
Setting station presets
Search for the desired stations by turning the “TUNE•SCROLL”
1
knob or pressing “∧” or “∨” on the “SEEK/TRACK” button.
2
Press and hold one of the station selectors (
) to be set until you
hear a beep.
∗: If equipped
RAV4_OM_OM0R012U_(U)
5-3. Using the radio
339
Scanning radio stations
■ Scanning the preset radio stations
1
Press and hold the “SCAN” button until you hear a beep.
Preset stations will be played for 5 seconds each.
To cancel, press the button again.
2
When the desired station is reached, press the button again.
■ Scanning all the radio stations within range
1
Press the “SCAN” button.
All the stations with reception will be played for 5 seconds each.
To cancel, press the button again.
When the desired station is reached, press the button again.
2
Switching the display
Press the “TEXT” button to display or hide the radio texts.
If there are continuing texts,
is displayed.
Press the button to display the remaining texts.
5
■ When the battery is disconnected
Stations presets are erased.
■ Reception sensitivity
● Maintaining perfect radio reception at all times is difficult due to the continu-
ally changing position of the antenna, differences in signal strength and sur-
rounding objects, such as trains, transmitters, etc.
● The radio antenna is mounted on the roof.
RAV4_OM_OM0R012U_(U)
