Toyota C-HR (2018 year). Manual - part 19

289

Interior features

5-1. Using the air conditioning

system and defogger

Air conditioning system ..... 290
Seat heaters...................... 298

5-2. Using the interior lights

Interior lights list ................ 300

• Interior lights ................. 301
• Personal lights .............. 302

5-3. Using the storage

features

List of storage features ..... 303

• Glove box...................... 304
• Console box.................. 304
• Bottle holders................ 305
• Cup holders .................. 306

Luggage compartment

features........................... 307

5-4. Using the other interior

features

Other interior features ....... 313

• Sun visors ..................... 313
• Vanity mirrors................ 313
• Clock............................. 314
• Power outlet.................. 315
• Assist grips ................... 316
• Steering wheel

audio switches .............. 317

• Using the

microphone ................... 318

290

5-1. Using the air conditioning system and defogger

Air conditioning system

■

Adjusting the temperature setting

Increases the temperature
Decreases the temperature

Air outlets are automatically selected and fan speed is automati-
cally adjusted according to the set temperature setting.

Air conditioning controls

291

5-1. Using the air conditioning system and defogger

rior fe

atures

■

Fan speed setting

Increases the fan speed
Decreases the fan speed

Press

to turn the fan off.

■

Change the airflow mode

To change the airflow mode,
move the airflow change knob
upward or downward.

The air outlets used are
changed each time the knob is
operated.

Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the
windshield defogger oper-
ates.

292

5-1. Using the air conditioning system and defogger

Press .

The dehumidification function begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature set-
ting.
Adjust the temperature setting.

To stop the operation, press

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

■

Adjusting the temperature for driver and passenger seats sep-
arately
To turn on the dual control mode, perform any of the following pro-
cedures:

● Press .

● Adjust the passenger’s side temperature setting.

The indicator comes on when the dual control mode is on.

Using automatic mode

293

5-1. Using the air conditioning system and defogger

rior fe

atures

■

Switching between outside air and recirculated air modes

Press .

The mode switches between outside air mode (indicator off) and recir-

culated air mode (indicator on) each time

is pressed.

■

Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.

Press .

The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the front side windows early, turn the air
flow and temperature up.

To return to the previous mode, press

again when the windshield

is defogged.

■

Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Press .

The defoggers will automatically turn off after a period of time.

Other functions

294

5-1. Using the air conditioning system and defogger

■

Climate control customization
Climate control setting can be changed.

Press .

The air conditioning is controlled with low fuel consumption prioritized
such as reducing fan speed, etc.

■

Location of air outlets

The air outlets and air volume
change according to the
selected airflow mode.
(

→P. 291)

■

Adjusting the position of and opening and closing the air out-
lets

Direct air flow to the left or
right, up or down.
Turn the knob to open or
close the vent.

Air outlets

295

5-1. Using the air conditioning system and defogger

rior fe

atures

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow

immediately after

is pressed.

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high.

Turning

on will dehumidify the air from the outlets and defog the

windshield effectively.

●

If you turn

off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads, in tunnels, or in heavy traffic set the outside/
recirculated air mode button to the recirculated air mode. This is effective in
preventing outside air from entering the vehicle interior. During cooling oper-
ation, setting the recirculated air mode will also cool the vehicle interior
effectively.

●

Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.

■

Operation of the air conditioning system in Eco drive mode

●

In Eco drive mode, the air conditioning system is controlled as follows to pri-
oritize fuel efficiency:
• Engine speed and compressor operation controlled to restrict heating/

cooling capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations:
• Adjust the fan speed
• Adjust the temperature setting
• Turn off Eco drive mode

●

Even when the drive mode is set to Eco drive mode, the air conditioning eco

mode can be turned off by pressing

296

5-1. Using the air conditioning system and defogger

■

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

●

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position (vehicles without a smart key system) or
IGNITION ON mode (vehicles with a smart key system).

●

It is possible to switch to outside air mode at any time by pressing

■

When the outside temperature falls to nearly 32

°F (0°C)

The dehumidification function may not operate even when

is pressed.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately after the air conditioning system is started in automatic
mode.

■

Air conditioning filter
→P. 370

■

Customization
Settings (e.g. air conditioning setting) can be changed.
(Customizable features

→P. 474)

297

5-1. Using the air conditioning system and defogger

rior fe

atures

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

■

To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

●

Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

298

5-1. Using the air conditioning system and defogger

Seat heaters

∗

: If equipped

Seat heaters heat the front seats.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
not running.

299

5-1. Using the air conditioning system and defogger

rior fe

atures

Each time the switch is pressed,
the operation condition changes
as follows.
Hi (3 segments lit)

→ Mid (2 seg-

ments lit)

→ Lo (1 segment lit) →

Off

The level indicator (amber) light up
during operation.

■

Operation condition



Vehicles without a smart key system

The seat heaters can be used when the engine switch is in the “ON” position.



Vehicles with a smart key system

The seat heaters can be used when the engine switch is in IGNITION ON
mode.

Operating instructions

300

5-2. Using the interior lights

Interior lights list

Vanity lights (if equipped) (

→P. 313)

Front interior light/front personal lights (

→P. 301, 30 2)

Rear interior light (

→P. 301)

Engine switch light (vehicles with a smart key system)
Glove box light (

→P. 304)

301

5-2. Using the interior lights

rior fe

atures

■

Front

Turns the door position on/off

■

Rear

On
Door position
Off

Interior lights

302

5-2. Using the interior lights

Turns the lights on/off

When the lights are on due to the
door link switch, a light will not turn
off even if its switch is pressed.

■

Illuminated entry system



Vehicles without a smart key system

When the interior light switch is in the door position, the interior lights auto-
matically turn on/off according to the engine switch position, whether the
doors are locked/unlocked and whether the doors are open/closed.



Vehicles with a smart key system

When the interior light switch is in the door position, the interior lights and
engine switch light automatically turn on/off according to engine switch mode,
the presence of the electronic key, whether the doors are locked/unlocked
and whether the doors are open/closed.

■

Outer mirror illumination (if equipped)
The illumination automatically turns on according to the presence of the elec-
tronic key (vehicles with a smart key system), or the doors are unlocked.

■

To prevent battery discharge
The following lights will turn off automatically after 20 minutes:

●

Front interior light/front personal lights

●

Rear interior light

●

Luggage compartment light

●

Vanity lights (if equipped)

■

Customization
Settings (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features:

→P. 474)

Personal lights

303

5-3. Using the storage features

rior fe

atures

List of storage features

Glove box

(

→P. 304)

Bottle holders

(

→P. 305)

Cup holders

(

→P. 306)

Console box

(

→P. 304)

WARNING

●

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact

with other stored items.

• Lighters or spray cans may explode. If they come into contact with other

stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.

●

When driving or when the storage compartments are not in use, keep the
lids closed and trays clear.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.

304

5-3. Using the storage features

Press the button to open the glove
box.

The glove box light turns on when the tail lights are on.

Lift the lid while pulling up the
knob.

Glove box

Console box

Content .. 17 18 19 20 ..
