Toyota ProAce (2017 year). Manual - part 21

Audio and Telematics

Toyota Pro Touch with navigation system

GPS satellite navigation - Connectivity - Multimedia audio - Bluetooth® telephone

Contents

First steps

342

Steering mounted controls

344

Menus 345

Voice commands

346

Navigation

352

Connected navigation

368

Connectivity

378

Radio Media

388

Telephone 400

Settings

412

Frequently asked questions

422

The system is protected in such a way that it will only operate in

As a safety measure and because it requires sustained attention

your vehicle.

by the driver, the pairing of a Bluetooth mobile telephone with

the Bluetooth hands-free system of your audio system must be

done with the vehicle stationary and the ignition on.

The display of the energy economy mode message signals that

a change to standby is imminent. For more information on the

Energy economy mode refer to the corresponding section.

341

Audio and Telematics

First steps

With the engine running, a press

Use the buttons either side of the touch screen

The touch screen is of the "capacitive"

mutes the sound.

for access to the menus, then press the virtual

type.

With the ignition off, a press turns the

buttons in the touch screen. All of the touch

To clean the screen, use a soft,

system on.

areas of the screen are white.

non-abrasive cloth (spectacles cloth)

Each menu is displayed in one or two pages

with no additional product.

Volume.

(primary page and secondary page).

Do not use sharp objects on the

screen.

Do not touch the screen with wet

hands.

Primary page

Secondary page

23 °C

87.5 MHz

12:13

FM/87.5 MHz

87.5MHz

342

Audio and Telematics

Short-cuts: using the virtual buttons in the

23 °C

531 kHz

12:13

In the "Settings" menu you can create

upper band of touch screen, it is possible to

a profile for just one person or a group

go directly to the selection of audio source,

of people with common points, with

the list of stations (or titles, depending on

the possibility of entering a multitude

the source), message notifications, emails,

of settings (radio presets, audio

mapping updates and, depending on services,

settings, navigation history, contact

navigation notifications.

favourites, ...); these settings are taken

into account automatically.

Select the audio source (depending on

version):

-

FM / DAB* / AM* stations.

-

Smartphone via MirrorLinkTM.

-

USB memory stick.

-

Media player connected to the auxiliary

socket (jack, cable not supplied).

-

Telephone connected by Bluetooth* and

In very hot conditions, the volume may

using Bluetooth* audio streaming.

be limited to protect the system. It may

go into standby (screen and sound off)

for at least 5 minutes.

The return to normal takes place when

the temperature in the passenger

compartment drops.

* Depending on equipment.

343

Audio and Telematics

Steering mounted controls

Voice commands:

Increase volume.

Radio (rotate): automatic search for

Short press, system voice

the previous / next station.

commands.

Media (rotate): previous / next track,

Long press, smartphone voice

move in a list.

commands via the system.

Short press: Confirm a selection.

Mute / Restore the sound.

Other than selection, access to

presets.

Decrease volume.

Media (short press): change the

Radio: display the list of stations.

multimedia source.

Media: display the list of tracks.

Telephone (short press): call.

Radio, press and hold: update the

Call in progress (short press):

list of stations received.

access to telephone menu.

Telephone (long press): reject an

incoming call, end call, access to

telephone menu.

344

Audio and Telematics

Menus

Connected navigation

Connectivity

Radio Media

23 °C

12:13

23 °C

531 kHz

12:13

23 °C

87.5 MHz

12:13

FM/87.5 MHz

87.5MHz

Enter navigation settings and choose a

Operate certain applications on a smartphone

Select an audio source, a radio station, display

destination.

connected via MirrorLinkTM.

photographs.

Use services available in real time, depending

Check the state of Bluetooth and Wi-Fi

on equipment.

connections.

Telephone

Settings

Driving

23 °C

531 kHz

12:13

23 °C

12:13

Connect a telephone by Bluetooth®, read

Enter settings for a personal profile and/

Activate, deactivate, adjust the settings for

messages and emails and send quick

or adjust the settings for sound (balance,

certain vehicle functions.

messages.

ambience, ...), and the display (language,

units, date, time, ...).

345

Audio and Telematics

Voice commands

Steering mounted controls

First steps

Information - Using the system

Pressing this button activates the

Example of a "voice command" for

Press the Push To Talk

voice commands function.

navigation:

button and tell me what you'd

"Navigate to address 11 Regent

like after the tone. Remember

Street, London".

you can interrupt me at any

Example of a "voice command" for

time by pressing this button. If you

To ensure that voice commands are

the radio and media:

press it again while I'm waiting for you

always recognised by the system,

"Play artist Madonna".

to speak, it'll end the conversation. If

please observe the following

you need to start over, say "cancel".

recommendations:

If you want to undo something, say

Example of a "voice command" for

-

speak in a normal tone without

"undo". And to get information and tips

the telephone:

breaking up words or raising your

at any time, just say "help". If you ask

"Call David Miller".

voice.

to me do something and there's some

-

always wait for the "beep" (audible

information missing that I need, I'll

signal) before speaking.

give you some examples or take you

-

for best operation, it is

through it step by step. There's more

recommended that the windows

The voice commands, with a choice

information available in "novice" mode.

and opening roof (if fitted) be

of 12 languages (English, French,

You can set the dialogue mode to

closed to avoid interference from

Italian, Spanish, German, Dutch,

"expert" when you feel comfortable.

extraneous noises.

Portuguese, Polish, Turkish, Russian,

-

before making a voice command,

Arabic, Brazilian), are made using the

ask other passengers to not speak.

language previously chosen and set in

the system.

The voice commands in Arabic for:

"Navigate to address" and "Display POI

in the city", are not available.

346

Audio and Telematics

Global voice commands

These commands can be made from any screen page after pressing the voice command or telephone button located on the steering wheel, as

long as there is no telephone call in progress.

"Voice command"

Help message

Help

Voice command help

There are lots of topics I can help you with.

Navigation help

You can say: "help with phone", "help with navigation", "help with media" or "help with

radio". For an overview on how to use voice controls, you can say "help with voice

Radio help

controls".

Media help

Telephone help

Set dialogue mode as <...>

Select "beginner" or "expert" mode.

Select profile <...>

Select profile 1, 2 or 3.

Yes

Say "yes" if I got that right. Otherwise, say "no" and we'll start that again.

No

347

Audio and Telematics

"Navigation" voice commands

These commands can be issued from any screen page after pressing the voice command or telephone button on the steering wheel, as long as

there is no telephone call in progress.

"Voice command"

Help message

Navigate home

To start guidance or add a stopover, say "navigate to" and then the address or contact

Navigate to work

name.

For example, "navigate to address 11 Regent Street, London", or "navigate to contact,

Navigate to preferred address <...>

John Miller".

You can specify if it's a preferred or recent destination. For example, "navigate to preferred

Navigate to contact <...>

address, Tennis club", "navigate to recent destination, 11 Regent Street, London".

Otherwise, just say, "navigate home". To see points of interest on a map, you can say

things like "show hotels in Banbury" or "show nearby petrol station".

Navigate to address <...>

For more information you can ask for "help with route guidance".

Show nearby POI <...>

Remaining distance

Remaining time

To get information about your current route, you can say "tell me the remaining time",

"distance" or "arrival time".

Arrival time

Try saying "help with navigation" to learn more commands.

Stop route guidance

Depending on the country, give the destination instructions (address) in the language used by the system.

348

Audio and Telematics

"Radio Media" voice commands

These commands can be issued from any screen page after pressing the voice command or telephone button on the steering wheel, as long as

there is no telephone call in progress.

"Voice command"

Help message

You can pick a radio station by saying "tune to" and the station name or frequency.

Tune to channel <...>

For example "tune to channel Talksport" or "tune to 98.5 FM". To listen to a preset radio

station, say "tune to preset number". For example "tune to preset number five".

To display the details of the current "track", "artist" and "album", you can say "What's

What's playing

playing"

Play song <...>

Use the command "play" to select the type of music you'd like to hear. You can pick by

Play artist <...>

"song", "artist", or "album". Just say something like "play artist, Madonna", "play song, Hey

Jude", or "play album, Thriller".

Play album <...>

Media voice commands are available only for a USB connection.

349

Audio and Telematics

"Telephone" voice commands

If a telephone is connected to the system, these voice commands can be issued from any main screen page after pressing the telephone

button on the steering wheel, as long as there is no telephone call in progress.

If there is no telephone connected by Bluetooth, a voice message announces: "Please first connect a telephone" and the voice session will be

closed.

"Voice command"

Help message

Call contact <...>*

To make a phone call, say "call" followed by the contact name, for example: "Call David

Dial <...>*

Miller".

You can also include the phone type, for example: "Call David Miller at home".

To make a call by number, say "dial" followed by the phone number, for example,

"Dial 107776 835 417".

Display contacts*

You can check your voicemail by saying "call voicemail".

To send a text, say "send quick message to", followed by the contact, and then the name

of the quick message you'd like to send.

For example, "send quick message to David Miller, I'll be late".

Display calls*

To display the list of calls, say "display calls". For more information on SMS, you can say

"help with texting".

Call (message box | voicemail)*

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and if the download has

been done.

350

Audio and Telematics

"Test message" voice commands

If a telephone is connected to the system these voice commands can be issued from any main screen page after pressing the telephone button

on the steering wheel, as long as there is no telephone call in progress.

If no telephone has been connected by Bluetooth, a voice message announces: "Please first connect a telephone" and the voice session will be

closed.

"Voice command"

Help message

To hear your messages, you can say "listen to most recent message".

Send text to <...>

When you want to send a text, there's a set of quick messages ready for you to use.

Just use the quick message name and say something like "send quick message to Bill

Carter, I'll be late".

Check the phone menu for the names of the supported messages.

Please say "call" or "send quick message to", and then select a line from the list.

To move around a list shown on the display, you can say "go to start", "go to end", "next

page" or "previous page".

To undo your selection, say "undo".

Listen to most recent message*

To cancel the current action and start again, say "cancel".

The system only sends predefined "Quick messages".

* This function is only available if the telephone connected to the system supports downloading of contacts and recent calls and if the download has

been done.

351

Audio and Telematics

Navigation

Level 1

Level 2

Level 3

23 °C

12:13

23 °C

12:13

1

352

Audio and Telematics

Level 1

Level 2

Level 3

Comments

Navigation

Select the orientation of the map; north up,

vehicle direction up or perspective.

Navigation

Display the traffic information available.

Manually locate an area on the world map or

World map

enter the latitude and longitude coordinates.

Around the vehicle

Around home

Display the location criteria selected.

Navigation

Around the destination

2D mode

Switch to a 2D map.

Zoom out.

Zoom in.

Start navigation to the current address.

Save the current address.

Zoom out.

Zoom in.

353

Audio and Telematics

Level 1

Level 2

Level 3

Point of interest on map

23 °C

12:13

2

3

4

5

6

23 °C

12:13

7

1

354

Audio and Telematics

Level 1

Level 2

Level 3

Comments

Stations

Activate or deactivate the content available

Car park

(stations, car parks, risk areas and danger

areas).

Danger area

Map color

Select day or night mode for display of the map.

2

Travel

3

Active life

4

Commercial

Select the POIs available.

POI on map

5

Public

6

Geographic

Navigation

Select all

Select or deselect all.

Confirm

Save your choice or selection.

7

Modify city

Select or modify a city.

Weather

Petrol Station

Display on the map the content available in non-

Car park

connected mode.

View map

Traffic

Danger area

Select POI

Select from the POIs available.

Zoom out.

Zoom in.

355

Audio and Telematics

Level 3

Level 4

Level 5

Filling stations located

Car parks around the vehicle

356
