Toyota C-HR Hybrid (2017 year). Manual - part 27

442

5-5. Using an external device

Listening USB memory device

Connecting a USB memory enables you to enjoy music from the

vehicle speakers. Press the “MODE” button until “USB” is dis-

played.

Connecting a USB memory

P. 420

Control panel

1

Changing the audio source/

6

Selecting a folder

playback

7

Displaying folder list

2

Tune/scroll knob

8

Displaying text message

Selecting a file

9

Power/volume knob

3

Selecting a file, fast-forward-

Press: Turning the audio sys-

ing or rewinding

tem on or off

4

Random play or back button

Turn: Adjusting the volume

5

Repeat play

C-HR_HV_OM_Europe_OM10538E

5-5. Using an external device

443

Selecting a folder

■ Selecting folders one at a time

Press

(“<FOLDER”) or

(“FOLDER>”) to select the

desired folder.

■ Selecting a folder and file from folder list

1

Press

(“LIST”).

The folder list will be displayed.

2

Turn and press the tune/scroll knob to select a folder and file.

To return to the previous display, press

(“BACK”).

■ Returning to the first folder

Press and hold

(“<FOLDER”) until you hear a beep.

Selecting a file

Turn the tune/scroll knob or press the “<” or “>” button of “SEEK

TRACK” to select the desired file.

5

Fast-forwarding and rewinding files

Press and hold the “<” or “>” button of “SEEK TRACK”.

Random play

Pressing

(“RDM”) changes modes in the following order:

Folder randomAll folder randomOff

Repeat play

Pressing

(“RPT”) changes modes in the following order:

File repeatFolder repeat*Off

*: Available except when RDM (random play) is selected

C-HR_HV_OM_Europe_OM10538E

444

5-5. Using an external device

Switching the display

Press

(“TEXT”) to display or hide the album title.

If there are continuing texts,

is displayed.

Press and hold the button to display the remaining texts.

■ USB memory functions

● Depending on the USB memory that is connected to the system, the device

itself may not be operable and certain functions may not be available. If the

device is inoperable or a function is unavailable due to a malfunction (as

opposed to a system specification), disconnecting the device and recon-

necting it once again may resolve the problem.

● If the USB memory still does not begin operation after being disconnected

and reconnected, format the memory.

■ Display

P. 429

■Error messages

If an error message is displayed, refer to the following table and take the

appropriate measures. If the problem is not rectified, take the vehicle to any

authorized Toyota retailer or Toyota authorized repairer, or any reliable

repairer.

Message

Cause/Correction procedures

This indicates a problem in the USB memory

“ERROR”

or its connection.

This indicates that no MP3/WMA files are

“NO MUSIC”

included in the USB memory.

C-HR_HV_OM_Europe_OM10538E

5-5. Using an external device

447

●Playback

• To play MP3 files with steady sound quality, we recommend a fixed bit

rate of at least 128 kbps and a sampling frequency of 44.1 kHz.

• There is a wide variety of freeware and other encoding software for MP3

and WMA files on the market, and depending on the status of the encod-

ing and the file format, poor sound quality or noise at the start of playback

may result. In some cases, playback may not be possible at all.

• Microsoft, Windows, and Windows Media are registered trademarks of

Microsoft Corporation in the U.S.A. and other countries.

WARNING

■ Caution while driving

Do not connect USB memory or operate the controls. Doing so may cause

an accident, resulting in death or serious injury.

NOTICE

■ To prevent damage to USB memory or its terminal

●Do not leave USB memory in the vehicle. The temperature inside the vehi-

cle may become high.

5

●Do not push down on or apply unnecessary pressure to the USB memory

while it is connected.

●Do not insert foreign objects into the port.

C-HR_HV_OM_Europe_OM10538E

448

5-5. Using an external device

Using the AUX port

This port can be used to connect a portable audio device and lis-

ten to it using the vehicle’s speakers. Press the “MODE” button

until “AUX” is displayed.

Connecting a portable player

P. 420

■ Operating portable audio devices connected to the audio system

The volume can be adjusted using the vehicle’s audio controls. All other

adjustments must be made on the portable audio device itself.

■ When using a portable audio device connected to the power outlet

Noise may occur during playback. Use the power source of the portable

audio device.

C-HR_HV_OM_Europe_OM10538E

450

5-6. Using Bluetooth® devices

Device registration/connection flow

1. Register the Bluetooth® device to be used with audio

system (P. 456)

2. Connect the registered Bluetooth® device to be used

(P. 457, 458)

3. Set automatic connection of the device

(P. 459)

4. Check Bluetooth® connection condition

(P. 451)

To be used for audio

To be used for hands-free phone

5. Use Bluetooth® audio

5. Use Bluetooth® phone

(P. 465)

(P. 467)

C-HR_HV_OM_Europe_OM10538E

5-6. Using Bluetooth® devices

451

Audio unit

1

Power/volume knob

Press: Turning the audio sys-

tem on or off

Turn: Adjusting the volume

2

Bluetooth® connection condi-

tion

If

“BT” is not displayed, the

Bluetooth® audio/phone cannot be

used.

3

Display

A message, name, number, etc., is displayed.

Lower-case characters and special characters may not be displayed.

4

Tune/scroll knob

Displays set up menu or selects items such as menu and number

Turn: Selects an item

Press: Displays set up menu or inputs the selected item

5

5

Selects speed dials (Bluetooth® phone operation)

6

On-hook switch

Turns the hands-free system off/ends a call/refuses a call

7

Off-hook switch

Turns the hands-free system on/starts a call

Press and hold: Displays information that is too long to be dis-

8

played at one time on the display (Bluetooth® audio operation)

C-HR_HV_OM_Europe_OM10538E

452

5-6. Using Bluetooth® devices

Microphone

C-HR_HV_OM_Europe_OM10538E

5-6. Using Bluetooth® devices

453

Menu list of the Bluetooth® audio/phone

To enter a menu, press the tune/scroll knob and navigate menus by

using the knob.

First menu

Second menu

Third menu

Operation details

Registering

a

“Pairing”

-

Bluetooth® device

Listing the registered

“List phone”

-

cellular phones

Listing the registered

“List audio”

-

portable players

Changing the pass-

“Passkey”

-

key

Setting

automatic

“Bluetooth*”

“BT Power”

-

connection of the

device on or off

“Device name”

Displaying

the

“Bluetooth* info”

“Device address”

device status

5

Setting the auto-

matic

connection

“Display setting”

-

confirmation display

to on or off

Initializing the set-

“Initialize”

-

tings

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

C-HR_HV_OM_Europe_OM10538E

454

5-6. Using Bluetooth® devices

First menu

Second menu

Third menu

Operation details

Adding a new num-

“Add contacts”

ber

Registering a speed

“Add SD”

dial

Deleting a number

“Delete call

stored in the call his-

“Phonebook”

history”

tory

Deleting a number

“Delete contacts”

stored in the phone-

“PHONE”

book

Deleting a phone-

“Delete other PB”

book’s data

“Call volume”

Setting call volume

“HF sound

“Ringtone

Setting ring tone vol-

setting”

volume”

ume

“Ringtone”

Setting the ring tone

“Transfer

Transferring the call

-

histories”

histories

■ Bluetooth® audio/phone system functions

Depending on the Bluetooth® device, certain functions may not be available.

C-HR_HV_OM_Europe_OM10538E

5-6. Using Bluetooth® devices

455

Using the steering wheel switches

The steering wheel switches can be used to operate a connected

cellular phone, or portable digital audio player (portable player).

Operating Bluetooth® phone using the steering wheel switches

1

Volume

The voice guidance volume

cannot be adjusted using this

button.

2

Off-hook switch

Turns the hands-free system

on/start a call

3

On-hook switch

Turns the hands-free system

off/ends a call/refuse a call

5

: If equipped

C-HR_HV_OM_Europe_OM10538E

456

5-6. Using Bluetooth® devices

Registering a Bluetooth® device

Before using the Bluetooth® audio/phone, it is necessary to reg-

ister a Bluetooth® device in the system. You can register up to 5

Bluetooth® devices.

How to register a Bluetooth® device

1

Press the tune/scroll knob and select “Bluetooth*” using the knob.

2

Press the knob and select “Pairing” using the knob.

A passkey will be displayed.

3

SSP (Secure Simple Pairing) incompatible Bluetooth® devices:

Input the passkey into the device.

SSP (Secure Simple Pairing) compatible Bluetooth® devices:

Select “YES” to register the device. Depending on the type of

device, it may register automatically.

If a Bluetooth® device has both music player and cellular phone func-

tions, both functions will be registered at the same time. When delet-

ing the device, both functions will be deleted at the same time.

If the off-hook switch is pressed and the “PHONE” mode is entered

when no phones have been registered, the registration screen will be

automatically displayed.

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

C-HR_HV_OM_Europe_OM10538E

5-7. “SETUP” menu

457

Using the “SETUP” menu (“Bluetooth*”

menu)

Registering a Bluetooth® device in the system allows the system

to function. The following functions can be used for registered

devices:

Registering a portable player

Select “Pairing” using the tune/scroll knob (P. 453), and perform the

procedure for registering a portable player. (P. 456)

Listing the registered cellular phones

Select “List Phone” using the tune/scroll knob. (P. 453) The list of

registered cellular phones will be displayed.

● Connecting the registered cellular phone to the audio system

1

Select the name of the cellular phone to be connected using the

5

tune/scroll knob.

2

Select “Select” using the knob.

● Deleting a registered cellular phone

1

Select the name of the cellular phone to be deleted using the

tune/scroll knob.

2

Select “Delete” using the knob.

3

Press

(“YES”).

● Disconnecting the registered cellular phone from the audio system

1

Select the name of the cellular phone to be disconnected using

the tune/scroll knob.

2

Select “Disconnect” using the knob.

3

Press

(“YES”).

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

C-HR_HV_OM_Europe_OM10538E

458

5-7. “SETUP” menu

Listing the registered portable players

Select “List audio” using the tune/scroll knob. (P. 453) The list of

registered portable players will be displayed.

● Connecting the registered portable player to the audio system

Select the name of the portable player to be connected using the

1

tune/scroll knob.

2

Select “Select” using the knob.

● Deleting the registered portable player

1

Select the name of the portable player to be deleted using the

tune/scroll knob.

2

Select “Delete” using the knob.

3

Press

(“YES”).

● Disconnecting the registered portable player from the audio system

1

Select the name of the portable player to be disconnected using

the tune/scroll knob.

2

Select “Disconnect” using the knob.

3

Press

(“YES”).

● Selecting the connection method

1

Select the name of the desired portable player using the tune/

scroll knob.

2

Select “Connection method” using the knob.

3

Select “From vehicle” or “From audio” using the knob.

C-HR_HV_OM_Europe_OM10538E

Content   ..  25  26  27  28   ..
