3-4. Adjusting the steering wheel and mirrors
187
■ After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
The horn may not sound if the steering wheel is not securely locked.
WARNING
■ Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.
■ After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
3
accident, resulting in death or serious injury. Also, the horn may not sound if
the steering wheel is not securely locked.
C-HR_HV_OM_Europe_OM10538E
188
3-4. Adjusting the steering wheel and mirrors
Inside rear view mirror
The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.
Adjusting the height of rear view mirror
The height of the rear view mirror can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.
Anti-glare function
Manual anti-glare inside rear view mirror
Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.
1
Normal position
2
Anti-glare position
C-HR_HV_OM_Europe_OM10538E
3-4. Adjusting the steering wheel and mirrors
189
Auto anti-glare inside rear view mirror
Responding to the level of brightness of the headlights of vehicles
behind, the reflected light is automatically reduced.
Changing automatic anti-glare
function mode
On/off
When the automatic anti-glare
function is in on mode, the indica-
tor illuminates.
The function will be set to on mode
each time the power switch is
Indicator
turned to ON mode.
Pressing the button turns the func-
3
tion to off mode. (The indicator also
turns off.)
■ To prevent sensor error (vehicles with an auto anti-glare inside rear view
mirror)
To ensure that the sensors operate prop-
erly, do not touch or cover them.
WARNING
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.
C-HR_HV_OM_Europe_OM10538E
190
3-4. Adjusting the steering wheel and mirrors
Outside rear view mirrors
Adjustment procedure
1
To select a mirror to adjust, turn
the switch.
1
Left
2
Right
2
To adjust the mirror, operate the
switch.
1
Up
2
Right
3
Down
4
Left
C-HR_HV_OM_Europe_OM10538E
3-4. Adjusting the steering wheel and mirrors
191
Folding and extending the mirrors
Manual type
Push the mirror back in the direc-
tion of the rear of the vehicle.
Power type
3
1
Folds the mirrors
2
Extends the mirrors
Putting the outside rear view mirror
folding switch in the neutral posi-
tion sets the mirrors to automatic
mode.
Automatic mode allows the folding
or extending of the mirrors to be
linked to locking/unlocking of the
doors.
■ Mirror angle can be adjusted when
The power switch is in ACCESSORY or ON mode.
■ When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. (P. 482)
C-HR_HV_OM_Europe_OM10538E
192
3-4. Adjusting the steering wheel and mirrors
■ Using the automatic folding/extending mirror function in cold weather (if
equipped)
When the automatic folding/extending mirror function is used in cold weather,
the outside rear view mirrors could freeze up and automatic folding and
extension may not be possible. In this event, remove any ice and snow from
the outside rear view mirror, then operate the mirror manually by using the
mirror fold switch or moving the mirror by hand.
■ Customization
The automatic mirror folding and extending operation can be changed.
(Customizable features: P. 679)
WARNING
■ Important points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.
●Do not adjust the mirrors while driving.
●Do not drive with the mirrors folded.
● Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.
■ When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.
■ When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.
C-HR_HV_OM_Europe_OM10538E
3-5. Opening and closing the windows
193
Power windows
Opening and closing procedures
The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:
1
Closing
2
One-touch closing*
3
Opening
4
One-touch opening*
*: To stop the window partway, oper-
3
ate the switch in the opposite direc-
tion.
Window lock switch
Press the switch down to lock the
passenger windows.
Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.
Press the switch again to unlock
the passenger windows.
C-HR_HV_OM_Europe_OM10538E
194
3-5. Opening and closing the windows
■ The power windows can be operated when
The power switch is in ON mode.
■ Operating the power windows after turning the hybrid system off
The power windows can be operated for approximately 45 seconds after the
power switch is turned to ACCESSORY mode or turned off. They cannot,
however, be operated once either front door is opened.
■ Jam protection function
If an object becomes jammed between the side window and the window
frame while the side window is closing, side window movement is stopped
and the side window is opened slightly.
■ Catch protection function
If an object becomes caught between the door and side window while the
side window is opening, side window movement is stopped.
C-HR_HV_OM_Europe_OM10538E
3-5. Opening and closing the windows
195
■ When the side window cannot be opened or closed
When the jam protection function or catch protection function operates
unusually and the side window cannot be opened or closed, perform the fol-
lowing operations with the power window switch of that door.
● Stop the vehicle. With the power switch in ON mode, within 4 seconds of the
jam protection function or catch protection function activating, continuously
operate the power window switch in the one-touch closing direction or one-
touch opening direction so that the side window can be opened and closed.
● If the side window cannot be opened and closed even when performing the
above operations, perform the following procedure for function initialization.
Turn the power switch to ON mode.
1
2
Pull and hold the power window switch in the one-touch closing direction
and completely close the side window.
3
Release the power window switch for a moment, resume pulling the
3
switch in the one-touch closing direction, and hold it there for approxi-
mately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direc-
4
tion. After the side window is completely opened, continue holding the
switch for an additional 1 second or more.
Release the power window switch for a moment, resume pushing the
5
switch in the one-touch opening direction, and hold it there for approxi-
mately 4 seconds or more.
Pull and hold the power window switch in the one-touch closing direction
6
again. After the side window is completely closed, continue holding the
switch for a further 1 second or more.
If you release the switch while the window is moving, start again from the
beginning. If the window reverses and cannot be fully closed or opened,
have the vehicle inspected by any authorized Toyota retailer or Toyota
authorized repairer, or any reliable repairer.
C-HR_HV_OM_Europe_OM10538E
196
3-5. Opening and closing the windows
■ Door lock linked window operation
● The power windows can be opened and closed using the mechanical key.*
(P. 648)
● The power windows can be opened and closed using the wireless remote
control.* (P. 150)
*: These settings must be customized at any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer.
■Power window open reminder function
The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the power switch is turned off and the driver’s
door is opened with the power windows open.
■ Customization
Some functions can be changed. (P. 679)
C-HR_HV_OM_Europe_OM10538E
3-5. Opening and closing the windows
197
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
■ Closing the windows
●The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch. (P. 193)
●Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
3
a side window is being operated.
●When using the wireless remote control or mechanical key (P. 144) and
operating the power windows, operate the power window after checking to
make sure that there is no possibility of any passenger having any of their
body parts caught in the side window. Also do not let a child operate side
window by the wireless remote control or mechanical key. It is possible for
children and other passengers to get caught in the power window.
● When exiting the vehicle, turn the power switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.
C-HR_HV_OM_Europe_OM10538E
198
3-5. Opening and closing the windows
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
■ Jam protection function
●Never use any part of your body to intentionally activate the jam protection
function.
●The jam protection function may not work if something gets jammed just
before the side window is fully closed. Be careful not to get any part of
your body jammed in the side window.
■ Catch protection function
●Never use any part of your body or clothing to intentionally activate the
catch protection function.
●The catch protection function may not work if something gets caught just
before the side window is fully opened. Be careful not to get any part of
your body or clothing caught in the side window.
C-HR_HV_OM_Europe_OM10538E
199
Driving
4
4-1.
Before driving
4-5.
Using the driving
Driving the vehicle
200
support systems
Cargo and luggage
211
Toyota Safety Sense
267
Trailer towing
212
PCS (Pre-Collision
System)
274
4-2.
Driving procedures
LDA (Lane Departure Alert
Power (ignition) switch
221
with steering control)
289
EV drive mode
228
RSA (Road Sign Assist)
301
Hybrid transmission
231
Dynamic radar cruise
Turn signal lever
235
control with full-speed
Parking brake
236
range
307
Brake hold
241
Cruise control
322
4-3.
Operating the lights
Driving mode select
328
and wipers
Speed limiter
330
Headlight switch
244
BSM
Automatic High Beam
249
(Blind Spot Monitor)
335
Fog light switch
254
• BSM function
341
Windshield wipers and
• RCTA function
346
washer
256
Toyota parking
Rear window wiper and
assist-sensor
351
washer
259
S-IPA (Simple Intelligent
Parking Assist
4-4.
Refueling
System)
363
Opening the fuel tank
Driving assist systems
402
cap
261
4-6.
Driving tips
Hybrid vehicle driving
tips
409
Winter driving tips
412
C-HR_HV_OM_Europe_OM10538E
200
4-1. Before driving
Driving the vehicle
The following procedures should be observed to ensure safe
driving:
Starting the hybrid system
P. 221
Driving
1
With the brake pedal depressed, shift the shift lever to D. (P. 231)
2
Release the parking brake. (P. 236)
If the parking brake is in automatic mode, the parking brake is released
automatically when shifting the shift lever to any position other than P.
(P. 236)
3
Gradually release the brake pedal and gently depress the accelera-
tor pedal to accelerate the vehicle.
Stopping
1
With the shift lever in D, depress the brake pedal.
2
If necessary, set the parking brake.
If the vehicle is to be stopped for an extended period of time, shift the shift
lever to P or N. (P. 231)
C-HR_HV_OM_Europe_OM10538E
4-1. Before driving
201
Parking the vehicle
1
With the shift lever in D. depress the brake pedal.
2
Set the parking brake (P. 236), and shift the shift lever to P
(P. 231).
If the parking brake is in automatic mode, the parking brake is set automat-
ically when shifting the shift lever to P. (P. 236)
If parking on a hill, block the wheels as needed.
3
Press the power switch to stop the hybrid system.
4
Lock the door, making sure that you have the electronic key on your
person.
Starting off on a steep uphill
1
With the brake pedal depressed, shift the shift lever to D.
2
Pull the parking brake switch and parking brake is set manually.
4
(P. 237)
3
Release the brake pedal and gently depress the accelerator pedal
to accelerate the vehicle.
4
Press the parking brake switch and parking brake is released man-
ually. (P. 237)
C-HR_HV_OM_Europe_OM10538E
202
4-1. Before driving
■ When starting off on a uphill
The hill-start assist control will activate. (P. 403)
■ For fuel-efficient driving
Keep in mind that hybrid vehicles are similar to conventional vehicles, and it
is necessary to refrain from activities such as sudden acceleration. (P. 409)
■ Driving in the rain
●Drive carefully when it is raining, because visibility will be reduced, the win-
dows may become fogged-up, and the road will be slippery.
●Drive carefully when it starts to rain, because the road surface will be espe-
cially slippery.
● Refrain from high speeds when driving on an expressway in the rain,
because there may be a layer of water between the tires and the road sur-
face, preventing the steering and brakes from operating properly.
■ Restraining hybrid system output (Brake Override System)
● When the accelerator and brake pedals are depressed at the same time, the
hybrid system output may be restrained.
● A warning message is displayed on the multi-information display while the
system is operating.
■ Restraining sudden start (Drive-Start Control)
● When the following unusual operation is performed, the hybrid system out-
put may be restrained.
• When the shift lever is shifted from R to D/B, D/B to R, N to R, P to D/B,
or P to R with the accelerator pedal depressed, a warning message
appears on the multi-information display.
• When the accelerator pedal is depressed too much while the vehicle is in
reverse.
● While Drive-Start Control is being activated, your vehicle may have trouble
escaping from the mud or fresh snow. In such case, deactivate TRC to can-
cel Drive-Start Control so that the vehicle may become able to escape from
the mud or fresh snow.
C-HR_HV_OM_Europe_OM10538E
4-1. Before driving
203
■ Breaking in your new Toyota
To extend the life of the vehicle, observing the following precautions is recom-
mended:
● For the first 300 km (200 miles):
Avoid sudden stops.
● For the first 800 km (500 miles):
Do not tow a trailer.
● For the first 1600 km (1000 miles):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive at a constant speed for extended periods.
■ Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the availability
of the correct fuel. (P. 669)
■ Eco-friendly driving
P. 127
4
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
■ When starting the vehicle
Always keep your foot on the brake pedal while stopped with the “READY”
indicator is illuminated. This prevents the vehicle from creeping.
C-HR_HV_OM_Europe_OM10538E
