Toyota Urban Cruiser (2015 year). Manual - part 11
1-7. Safety information
■ Selecting an appropriate child restraint system
●Use a child restraint system appropriate for the child until the child
becomes large enough to properly wear the vehicle’s seat belt.
●If a child is too large for a child restraint system, sit the child on a rear
seat and use the vehicle’s seat belt. (→P. 86)
CAUTION
■ Using a child restraint system
The use of a child restraint system not suitable for the vehicle may not prop-
erly secure the infant or child. It may result in death or serious injury (in the
event of sudden braking or an accident).
■ Child restraint precautions
●For effective protection in automobile accidents and sudden stops, a child
must be properly restrained, using a seat belt or child restraint system
depending on the age and size of the child. Holding a child in your arms is
not a substitute for a child restraint system. In an accident, the child can be
crushed against the windshield, or between you and the vehicle’s interior.
● Toyota strongly urges the use of a proper child restraint system that con-
forms to the size of the child, installed on the rear seat. According to acci-
dent statistics, the child is safer when properly restrained in the rear seat
than in the front seat.
●Never use a rear-facing child restraint system on the front passenger seat
when the airbag manual on-off switch is on. (→P. 140)
In the event of an accident, the force of the rapid inflation of the front pas-
senger airbag can cause death or serious injury to the child.
150
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
CAUTION
■ Child restraint precautions
● A forward-facing child restraint system may be installed on the front pas-
senger seat only when it is unavoidable. A child restraint system that
1
requires a top tether strap should not be used in the front passenger seat
since there is no top tether strap anchor for the front passenger seat.
Adjust the seatback as upright as possible and always move the seat as
far back as possible because the front passenger airbag could inflate with
considerable speed and force. Otherwise, the child may be killed or seri-
ously injured.
●Do not allow the child to lean his/her head or any part of his/her body
against the door or the area of the seat, front and rear pillars or roof side
rails from which the SRS side airbags or SRS curtain shield airbags deploy
even if the child is seated in the child restraint system. It is dangerous if
the SRS side airbags and curtain shield airbags inflate, and the impact
could cause death or serious injury to the child.
● Make sure you have complied with all installation instructions provided by
the child restraint manufacturer and that the system is properly secured. If
it is not secured properly, it may cause death or serious injury to the child
in the event of a sudden stop, sudden swerve or an accident.
151
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
CAUTION
■ When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes
twisted around a child’s neck, it may lead to choking or other serious injuries
that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used
to cut the belt.
■ When the child restraint system is not in use
●Keep the child restraint system properly secured on the seat even if it is
not in use.
Do not store the child restraint system unsecured in the passenger com-
partment.
● If it is necessary to detach the child restraint system, remove it from the
vehicle or store it securely in the luggage compartment. This will prevent it
from injuring passengers in the event of a sudden stop, sudden swerve or
an accident.
152
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
Installing child restraints
Follow the child restraint system manufacturer’s instructions. Firmly
secure the child restraints to the outside rear seats using a seat belt
or a ISOFIX rigid anchor (ISOFIX child restraint system). Attach the
top strap when installing a child restraint system.
1
Seat belts
(An ELR belt
requires a locking clip.)
ISOFIX rigid anchor
(ISOFIX
child restraint system)
These exclusive fixing bars are
provided for the outside rear
seats. (Buttons displaying the
location of the anchors are
attached to the seats.)
153
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
Anchor bracket (for top strap)
Anchor brackets are provided
for outside rear seats.
154
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
Installing child restraints using a seat belt
■ Rear-facing Baby seat/child seat
STEP
1
Fold the seatback while pulling
the seatback angle adjustment
1
lever up. Return the seatback
and secure it at the first lock
position (most upright position).
(→P. 77)
STEP
2
Place the child restraint system
on the rear seat facing the rear
of the vehicle.
STEP
3
Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.
Keep the lap portion of the belt
tight.
155
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
STEP
4
Install a locking clip near the tab
of the lap and shoulder belt by
inserting the lap and shoulder
webbing through the recesses of
the locking clip.
■ Forward-facing Child seat
STEP
1
Fold the seatback while pulling
the seatback angle adjustment
lever up. Return the seatback
and secure it at the first lock
position (most upright position).
(→P. 77)
STEP
2
Place the child restraint system
on the seat facing the front of the
vehicle.
156
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
STEP
3
Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.
Keep the lap portion of the belt
1
tight.
STEP
4
Install a locking clip near the tab
of the lap and shoulder belt by
inserting the lap and shoulder
webbing through the recesses of
the locking clip.
157
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
■ Junior seat
STEP
1
Fold the seatback while pulling
the seatback angle adjustment
lever up. Return the seatback
and secure it at the first lock
position (most upright position).
(→P. 77)
STEP
2
Place the child restraint system
on the seat facing the front of the
vehicle.
STEP
3
Sit the child in the child restraint
system. Fit the seat belt to the
child restraint system according
to the manufacturer’s instruc-
tions and insert the plate into the
buckle. Make sure that the belt is
not twisted.
Check that the shoulder belt is
correctly positioned over the
child’s shoulder, and that the lap
belt is as low as possible.
(→P. 86)
158
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
Removing a child restraint system installed with a seat belt
Push the buckle release button
and fully retract the seat belt.
1
Installation with ISOFIX rigid anchor
(ISOFIX child restraint
system)
STEP
1
Fold the seatback while pulling
the seatback angle adjustment
lever up. Return the seatback
and secure it at the first lock
position (most upright position).
(→P. 77)
159
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
STEP
2
Check the positions of the exclu-
sive fixing bars, and install the
child restraint system to the seat.
The bars are installed in the
clearance between the seat cush-
ion and seatback.
If the child restraint has a top
strap, the top strap should be
latched onto the anchors.
160
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
Child restraint systems with a top strap
STEP
1
Secure the child restraint system using a seat belt or ISOFIX
rigid anchors, and do the following.
Remove the head restraint.
1
(→P. 83)
STEP
2
Latch the hook onto the anchor
bracket and tighten the top strap.
Make sure the top strap is
securely latched.
STEP
3
Replace the head restraint to the
upmost position.
161
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
■ When installing a child restraint system in the front passenger’s seat
or rear seat
You need a locking clip to install the child restraint system. Follow the
instructions provided by the manufacturer of the system. If your child
restraint system does not provide a locking clip, you can purchase the fol-
lowing item from any authorized Toyota dealer or repairer, or another duly
qualified and equipped professional.
Locking clip for child restraint system
(Part No. 73119-22010)
CAUTION
■ When installing a child restraint system
Follow the directions given in the child restraint system installation manual
and fix the child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child or other
passengers may be seriously injured or even killed in the event of sudden
braking, sudden swerving or an accident.
162
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
CAUTION
■ When installing a child restraint system
● If the driver’s seat interferes with the
child restraint system and prevents it
1
from being attached correctly, attach
the child restraint system to the right-
hand rear seat (left-hand drive vehicles)
or the left-hand rear seat
(right-hand
drive vehicles).
● Adjust the front passenger seat so that
it does not interfere with the child
restraint system.
● Only put a forward facing child restraint
system on the front seat when unavoid-
able. When installing a forward-facing
child restraint on the front passenger
seat, move the seat as far back as pos-
sible.
Failing to do so may result in death or
serious injury if the airbags deploy
(inflate).
163
URBAN CRUISER_OM_OM52F47E_(EE)
1-7. Safety information
CAUTION
■ When installing a child restraint system
●2WD models: When installing a rear-
facing child restraint system in the rear
seat, move the rear seat to the rear-
most lock position to prevent the child
restraint system from interfering with
the front seat. Otherwise, the child
restraint system may not be properly
secured. In the event of an accident,
this may cause death or serious injury.
● Never use a rear-facing child restraint
system on the front passenger seat
when the airbag manual on-off switch is
on. (→P. 140)
The force of the rapid inflation of the
front passenger airbag can cause death
or serious injury to children in the event
of an accident.
164
