POWER STEERING – VANE PUMP PS–11 PS 3. INSPECT FLOW CONTROL VALVE and check that it falls smoothly into the flow control (b) Check the flow control valve for leakage. Close one of the holes and apply compressed air of 392 to 490 kPa (4 to 5 kgf/cm 2 , 57 to 71 psi) to the hole on the opposite side. Confirm that the air does not flow out 4. INSPECT COMPRESSION SPRING the spring. 29.2 mm (1.150 in.) If it is not within the specification, replace the vane 5. INSPECT PRESSURE PORT UNION SUB-ASSEMBLY damaged, it could cause fluid leakage, so replace F051270 Compressed Air F052069E02 Vernier Caliper R008702E02 |
