Display
Status
When charging the
high voltage bat-
tery by using the
engine power
while the vehicle is
stopped
When there is no
energy current
Remaining high
voltage battery
power is
(1) low
(2) high
Operating/stop-
ping of the engine
(1) While stopped
(illuminated in
gray)
(2) While operat-
ing (illumi-
nated in or-
ange)
Display
Status
Operating/stop-
ping of the electric
motor
(1) While stopped
(illuminated in
gray)
(2) While operat-
ing (illumi-
nated in green
or aqua blue)
In addition, if a warning or malfunction is
detected in the hybrid system, an inter-
ruption screen will be displayed on the
multi function display. For details, refer to
“Interruption screen” F3-34.
NOTE
. High voltage battery power is con-
sumed more than usual when driving
only using the electric motor power for
a long time.
. High voltage battery power is con-
sumed more than usual when the
vehicle is continuously or repeatedly
driven only using the electric motor
power. Although this is not a problem,
avoid stop-and-go driving as much as
possible by methods such as checking
traffic reports before you start driving.
. The indicator of the remaining high
voltage battery power may show empty
when the remaining power is extremely
low. However, this does not indicate a
malfunction.
