Subaru Impreza WRX (2014 year). Instruction

2-12

Keys and doors/Remote keyless entry system

ity reasons. It is recommended that you
have your dealer program all of your
transmitters into your system.

Programming the transmitters

The remote keyless entry system is
equipped with a special code learning
feature that allows you to program new
transmitter codes into the system or to
delete old ones. The system can learn up
to four unique transmitter codes. The four
transmitter codes may be the same or
different.
Programming transmitter codes into
system:

Bag containing transmitter

Transmitter circuit board

To register a new transmitter with the
remote keyless entry system, it is neces-
sary to program the transmitter’s code
(identification number) into the system. A
label showing the code is affixed to the
bag containing the transmitter, and an-
other is affixed to the circuit board inside
the transmitter. If there is no bag, open the
transmitter case and make a note of the
eight-digit number. Program the number
into the system in accordance with the
following procedure:
1. Firmly close the doors and the rear
gate, or trunk lid.
2. Open the driver’s door, sit in the
driver’s seat, and close the door.
3. Perform the following steps within 45
seconds.

(1) Open and close the driver’s door
once.

LOCK

(2) Insert the key into the ignition
switch, then turn it from the “LOCK”

position to the “ON” position 10 times
within 15 seconds.

NOTE

. When you complete step (2), an
electronic tone will sound once.
. If you do not perform steps (1) and
(2) within 45 seconds, an error will
occur. Neither an electronic tone nor
the buzzer will sound, and the interior
lamp will not flash. In this event, per-
form the whole procedure again begin-
ning with part 1.

4. Open and close the door once within
15 seconds.

NOTE

. When part 4 of the procedure is
completed, an electronic tone will
sound for 30 seconds.
. If you do not perform the operations
in part 4 within 15 seconds, an error
will occur and the electronic tone will
not sound. In this event, perform the
registration steps again beginning with
part 3 of the procedure.

5. Before the electronic tone stops
sounding, push the lock side of the power
door lock switch the same number of
times as the leftmost digit of the transmit-
ter code. For example, push the lock
switch eight times if the leftmost digit of
the code is 8.

NOTE

. The electronic tone will stop sound-
ing when you start entering the num-
ber.
. If you do not start entering the
number using the lock switch before
the electronic tone stops sounding, an
error will occur. In this event, perform
the registration steps again beginning
with part 3 of the procedure.
. If the interval between one push of

the switch and the next exceeds 5
seconds, an error will occur. In this
event, perform the procedure again
beginning with part 4. If an error occurs
six times, perform the procedure again
starting with part 3.

6. When you have finished entering the
number, push the unlock side of the lock
switch within 5 seconds.

NOTE

. An electronic tone will sound.
. If you push the unlock side of the
lock switch when more than 5 seconds
have passed, an error will occur. In this
event, perform the procedure again
beginning with part 4. If an error occurs
six times, perform the procedure again
starting with part 3.

Keys and doors/Remote keyless entry system

2-13

– CONTINUED –

2-14

Keys and doors/Remote keyless entry system

7. Perform parts 5 and 6 of the procedure
for each of the remaining digits of the
transmitter code beginning with the sec-
ond digit (counting from the left) and
finishing with the eighth digit.

NOTE

. When you finish entering the eighth
digit, an electronic tone will sound for
30 seconds.
. If the interval between one push of
the switch and the next exceeds 5
seconds, an error will occur. In this
event, perform the procedure again
beginning with part 4. If an error occurs
six times, perform the procedure again
starting with part 3.

8. Before the electronic tone stops
sounding, use the power door lock switch
to reenter the transmitter code beginning
with the leftmost digit.

NOTE

If you do not start entering the number
using the lock switch before the elec-
tronic tone stops sounding, an error
will occur. In this event, perform the
procedure again beginning with part 3.

9. When you have finished entering the
code a second time, an electronic tone will
sound for 1 second and automatic door
locking and unlocking operation will take

place once to indicate completion of
registration, provided the code entered
the second time is identical to that entered
the first time.

NOTE

If the code entered the second time is
not identical to the code entered the
first time, an error will occur. In this
event, perform the procedure again
beginning with part 5. If an error occurs
five times, perform the procedure again
starting with part 3.

10. If you wish to program another trans-
mitter code into the system (up to four
transmitter codes can be programmed into
the system), perform the procedure begin-
ning with part 4. When you have finished
programming all of the necessary trans-
mitter codes into the system, remove the
key from the ignition switch.
11. Test every registered transmitter to
confirm correct operation.

Deleting old transmitter codes

The control unit of the remote keyless
entry system has four memory locations to
store transmitter codes, giving it the ability
to operate with up to four transmitters.
When you lose a transmitter, the lost
transmitter’s code remains in the memory.
For security reasons, lost transmitter

codes should be deleted from the mem-
ory.
To delete old transmitter codes, program
four transmitter codes into the system. If
you have only one current transmitter,
program it four times. If you have two
current transmitters, program each one
twice. If you have three current transmit-
ters, program two of them once and the
third one twice. This process will leave
only current transmitter codes in the
system’s memory.

NOTE

Make sure no one else is operating
their keyless entry system within range
of your vehicle when programming
transmitters. If someone else were to
operate their remote transmitter while
you are programming your transmit-
ters, it is possible that their transmitter
code will be programmed into your
system, allowing them unauthorized
access to your vehicle.

Alarm system

The alarm system helps to protect your
vehicle and valuables from theft. The horn
sounds and the turn signal lights flash if
someone attempts to break into your
vehicle.

The system can be armed and disarmed
with the remote transmitter.
The system does not operate when the
key is inserted into the ignition switch.

Your vehicle’s alarm system has been set
for activation at the time of shipment from
the factory. You can set the system for
deactivation yourself or have it done by
your SUBARU dealer.

System operation

The alarm system will sound the following
alarms when triggered.
. The vehicle’s horn will sound for 30
seconds.
. The turn signal lights will flash for 30
seconds.

If any of the doors or the rear gate/trunk lid
remains open after the 30-second period,
the horn will continue to sound for a
maximum of 3 minutes. If the door or the
rear gate/trunk lid is closed while the horn

is sounding, the horn will stop sounding
with a delay of up to 30 seconds.

The alarm is triggered by:
. Opening any of the doors, the rear gate
or trunk lid
. Physical impact to the vehicle, such as
forced entry (only models with shock
sensors (dealer option))

NOTE

The alarm system can be set to trigger
the illumination of the following interior
lights.
. Dome light (illuminates only when
the dome light switch is in the “DOOR”
position)
. Map lights (models with moonroof)

The notifications regarding the dome
light and the map lights are deactivated
as the factory setting. A SUBARU
dealer can activate the system. Contact
your SUBARU dealer for details.

Activating and deactivating
the alarm system

To change the setting of your vehicle’s
alarm system for activation or deactiva-
tion, do the following.
1. Disarm the alarm system. Refer to
“Disarming the system” F2-17.

2. Sit in the driver’s seat and shut all
doors (and the rear gate if your vehicle is a
5-door).
3. Turn the ignition switch to the “ON”
position.
4. Hold down the REAR (UNLOCK) side
of the driver’s power door locking switch,
open the driver’s door within the following
1 second, and wait 10 seconds without
releasing the switch. The setting will then
be changed as follows.

If the system was previously activated:
The odometer/trip meter screen displays
“AL oF” and the horn sounds twice,
indicating that the system is now deacti-
vated.
If the system was previously deacti-
vated:
The odometer/trip meter screen displays
“AL on” and the horn sounds once,
indicating that the system is now acti-
vated.

NOTE

You may have the above setting
change done by your SUBARU dealer.

Keys and doors/Alarm system

2-15

– CONTINUED –

2-16

Keys and doors/Alarm system

If you have accidentally trig-
gered the alarm system

To stop the alarm

Do any of the following operations:
. Press any button on the remote trans-
mitter.
. Turn the ignition switch to the “ON”
position.

NOTE

Only registered keys will stop the
alarm. If the immobilizer transponder
is not registered, the alarm will not
stop.

Arming the system

To arm the system using remote
transmitter

1. Close all windows.
2. Remove the key from the ignition
switch.
3. Open the doors and get out of the
vehicle.
4. Make sure that the engine hood (and
the trunk lid on the 4-door) are locked.
5. Close all doors (and the rear gate on
the 5-door).

: Press to Arm the system.

: Press to Disarm the system.

6. Briefly press the “ ” button (for less
than 2 seconds). All doors (and the rear
gate on the 5-door) will lock, an electronic
chirp will sound once, the turn signal lights

will flash once, and the security indicator
light will start flashing rapidly. After rapid
flashing for 30 seconds (standby time), the
indicator lights will then flash slowly (twice
approximately every 2 seconds), indicat-
ing that the system has been armed for
surveillance.

If any of the doors, (rear gate or trunk lid)
is not fully closed, an electronic chirp
sounds five times, the turn signal lights
flash five times to alert you that the doors
(or the rear gate) are not properly closed.
When you close the door, the system will
automatically arm and doors will automa-
tically lock.

To arm the system using power
door locking switches

1. Close all windows.
2. Remove the key from the ignition
switch.
3. Open the doors and get out of the
vehicle.
4. Make sure that the engine hood is
locked.
5. Close the doors (and the rear gate on
the 5-door) but leave only the driver’s door
or the front passenger’s door open.

6. Push the front side (“LOCK” side) of
the power door locking switch to set the
door locks.
7. Close the door. An electronic chirp will
sound once, the turn signal lights will flash
once and the security indicator light will
start flashing rapidly. After rapid flashing
for 30 seconds (standby time), the indi-
cator lights will then flash slowly (twice
approximately every 2 seconds), indicat-
ing that the system has been armed for
surveillance.

NOTE

. The system can be armed even if the
engine hood and/or the windows are
opened. Always make sure that they
are fully closed before arming the
system.

. The 30-second standby time can be
eliminated if you prefer. Have it per-
formed by your SUBARU dealer.
. If your vehicle is a 4-door and you
unlock the trunk using the remote
transmitter’s “

” button with the

alarm system armed, the system will
be temporarily placed in a standby
state. The system will go back to the
surveillance state upon locking the
trunk.
. The system is in the standby mode
for a 30-second period after locking the
doors with the remote transmitter. The
security indicator light will flash at
short intervals during this period.
. If any of the following actions are
done during the standby period, the
system will not switch to the surveil-
lance state.

– Doors are unlocked using the
remote transmitter.
– Any door (including the rear gate
of a 5-door or the trunk of a 4-door)
is opened.
– Ignition switch is turned to the
“ON” position.

Disarming the system

Briefly press the “

” button (for less than

2 seconds) on the remote transmitter. The
driver’s door will unlock, an electronic

chirp will sound twice, the turn signal
lights will flash twice. The flashing of the
security indicator light will then change
slowly (once approximately every 3 sec-
onds from twice approximately every 2
seconds), indicating that the alarm system
has been disarmed.

NOTE

After disarming the alarm system,
briefly press the “

” button a second

time within 5 seconds to unlock all
other doors and the rear gate (5-door).

Emergency disarming

If you cannot disarm the system using the
transmitter (i.e. the transmitter is lost,
broken or the transmitter battery is too
weak), you can disarm the system without
using the transmitter as follows.
. Turn the ignition switch from the
“LOCK” to the “ON” position with a
registered key.

Valet mode

When you choose the valet mode, the
alarm system does not operate. In valet
mode, the remote transmitter is used only
for locking and unlocking the doors and
rear gate (5-door) and panic activation.

To enter the valet mode, change the
setting of your vehicle’s alarm system for

Keys and doors/Alarm system

2-17

– CONTINUED –

2-18

Keys and doors/Alarm system

deactivation mode. Refer to “Activating
and deactivating the alarm system” F2-
15. The security indicator light will con-
tinue to flash once every 3 seconds
indicating that the system is in the valet
mode.

To exit valet mode, change the setting of
your vehicle’s alarm system for activation
mode. Refer to “Activating and deactivat-
ing the alarm system” F2-15.

Passive arming

When passive arming mode has been
programmed by the dealer, arming of the
system is automatically accomplished
without using the remote transmitter. Note
that in this mode, DOORS MUST BE
MANUALLY LOCKED.

To enter the passive mode

If you wish to program the passive arming
mode, have it done by your SUBARU
dealer.

Arming the system

CAUTION

In passive mode, the system will
automatically activate the alarm but
WILL NOT automatically lock the
doors. In order to lock the doors
you must either lock them as in-
dicated in step 4 below or with the
key once they have been closed.
Failure to lock the doors instructionly
will result in a higher security risk.

1. Turn the ignition switch to the “ON”
position.

LOCK

2. Turn the ignition switch from “ON” to

“LOCK” position and remove the key from
the ignition switch.
3. Open the doors and get out of the
vehicle.

4. Before closing the doors, lock all doors
with the inside door lock levers.
5. Close the doors. The system will
automatically arm after 1 minute.

In the passive mode, the system can also
be armed with the remote transmitter or
with the power door locking switches. If
the remote transmitter or power door
locking switch is used to lock the vehicle,
arming will take place immediately regard-
less of whether or not the passive mode
has been selected.

Disarming the system

To disarm the system, briefly press the
“

” button on the transmitter.

Tripped sensor identification

The security indicator light flashes when
the alarm system has been triggered.
Also, the number of flashes indicates the
location of unauthorized intrusion or the
severity of impact on the vehicle.

When the ignition switch is turned to the
“ON” position, the indicator light will light
for 1 second and then flash as follows.
. When a door or rear gate (5-door) was
opened: 5 times
. When a door or the trunk (4-door) was
opened: 4 times
. When the ignition switch was turned to
the “ON” position: 3 times
. When a strong impact or multiple
impacts were sensed: twice (only models
with shock sensors (dealer option))
. When a light impact was sensed: once
(only models with shock sensors (dealer
option))

NOTE

Any of the above indicator light flash-
ings will recur each time the ignition
switch is turned to the “ON” position.
Rearming the alarm system cancels the

flashing.

Shock sensors (dealer op-
tion)

The shock sensors trigger the alarm
system when they sense impacts applied
to the vehicle and when any of their
electric wires are cut. The alarm system
causes the horn to sound and the turn
signal lights to flash for a short time when
the sensed impact is weak, but it warns of
a strong impact or multiple impacts by
sounding the horn and flashing the turn
signal lights, both lasting approximately 30
seconds.
If you desire, your SUBARU dealer can
connect them and set them for activation
or deactivation.

NOTE

. The shock sensors are not always
able to sense impacts caused by break-
ing in, and cannot sense an impact that
does not cause vibration (such as
breaking the glass using a rescue
hammer).
. The shock sensors may sense vi-
bration as indicated in the following
examples and trigger the alarm system.
Select the settings of the alarm system
and shock sensors appropriately de-
pending on where you usually park

your vehicle.
Examples:

– Vibration from a construction site
– Vibration in a multistory car park
– Vibration from trains

. You can have the sensitivity of the
shock sensors adjusted to your pre-
ference by your SUBARU dealer.

Keys and doors/Alarm system

2-19

2-20

Keys and doors/Child safety locks

Child safety locks

Each rear door has a child safety lock that
prevents the door from being opened even
if the inside door handle is pulled.
When the child safety lock lever is in the
lock position, the door cannot be opened
from inside regardless of the position of
the inner door handle lock lever. The door
can only be opened from the outside.

WARNING

Always turn the child safety locks to
the “LOCK” position when children
sit in the rear seat. Serious injury
could result if a child accidentally
opens the door and falls out.

Windows

Power windows

WARNING

To avoid serious personal injury
caused by entrapment, always obey
the following instructions without
exception.

. When operating the power win-

dows, be extremely careful to
prevent anyone’s fingers, arms,
neck, head or other objects from
being caught in the window.

. Always lock the passengers’ win-

dows using the lock switch when
children are riding in the vehicle.

. Before leaving the vehicle, al-

ways remove the key from the
ignition switch for safety and
never allow an unattended child
to remain in the vehicle. Failure
to follow this procedure could
result in injury to a child operat-
ing the power window.

The power windows operate only when
the ignition switch is in the “ON” position.

Driver’s side switches

Lock switch

For driver’s window (with one-touch auto

up and down feature)

For front passenger’s window

For rear left window

For rear right window

All door windows can be controlled by the
power window switch cluster at the driver
side door.

Operating the driver’s window

Automatically open/close

Open/close

To open:
Push the switch down lightly and hold it.
The window will open as long as the
switch is held.
This switch also has a one-touch auto
down feature that allows the window to be
opened fully without holding the switch.
Push the switch down until it clicks and
release it, and the window will fully open.
To stop the window halfway, pull the
switch up lightly.

To close:
Pull the switch up lightly and hold it. The
window will close as long as the switch is
held.

This switch also has a one-touch auto up
feature that allows the window to be
closed fully without holding the switch.
Pull the switch up until it clicks and release
it, and the window will fully close. To stop
the window halfway, push the switch down
lightly.

NOTE

If the vehicle’s battery is disconnected
due to situations such as battery or
fuse replacement, the one-touch auto
up/down function is deactivated. Initi-
alize the power window to reactivate
the one-touch auto up/down function.
Refer to “Initialization of power win-
dow” F2-23.

Anti-entrapment function

CAUTION

. Never attempt to test this func-

tion using fingers, hands or other
parts of your body.

. The anti-entrapment function

may not operate properly if some
object gets trapped just before
the window fully closes.

NOTE

. If a window detects an impact simi-
lar to that caused by trapping an object
(for example, when the vehicle encoun-
ters a deep pothole), the anti-entrap-
ment function may operate.
. The window cannot be operated for
a few seconds after the anti-entrap-
ment function operates.
. If the vehicle’s battery is discon-
nected due to situations such as
battery or fuse replacement, the anti-
entrapment function is deactivated.
Initialize the power window to reacti-
vate the anti-entrapment function. Re-
fer to “Initialization of power window”
F2-23.
While closing the driver’s window auto-
matically, if the window senses a sub-
stantial enough object trapped between
the window and the window frame, it
automatically moves down slightly and
stops.

Keys and doors/Windows

2-21

– CONTINUED –

2-22

Keys and doors/Windows

Operating the passengers’ win-
dows

To open:
Push the appropriate switch down and
hold it until the window reaches the
desired position.
To close:
Pull the switch up and hold it until the
window reaches the desired position.

Locking the passengers’ win-
dows

Lock

Unlock

Push the lock switch. When the lock
switch is in the “LOCK” position, the
passengers’ windows cannot be opened
or closed.
Push the switch again to cancel the
passengers’ window locking.

Passengers’ side switches

Open

To open:
Push the switch down and hold it until the
window reaches the desired position.
To close:
Pull the switch up and hold it until the
window reaches the desired position.

When the lock switch on the power
window switch cluster, located on the
driver’s side door, is in the “LOCK”
position, the passengers’ windows cannot
be operated with the passengers’
switches.

Initialization of power window

If the vehicle’s battery is disconnected due
to situations such as battery or fuse
replacement, the following functions are
deactivated.
. One-touch auto up/down function
. Anti-entrapment function

Initialize the power window using the
following procedure to reactivate these
functions.
1. Close the driver’s door.
2. Turn the ignition switch to the “ON”
position.
3. Open the driver’s side window halfway
by pushing down the power window
switch.
4. Pull up the power window switch and
close the window completely. Continue
pulling up the switch for approximately 1
second after the window is closed com-
pletely.

Trunk lid (4-door)

WARNING

. To prevent dangerous exhaust

gas from entering the vehicle,
always keep the trunk lid closed
while driving.

. Help prevent children, adults or

animals from locking themselves
in the trunk. On hot or sunny
days, the temperature in the
trunk could quickly become high
enough to cause death or serious
heat-related injuries including
brain damage to anyone locked
inside, particularly for small chil-
dren.

. When leaving the vehicle, either

close all windows and lock all
doors. Also make certain that the
trunk is closed.

To open and close the trunk
lid from outside

The trunk lid can be opened using the
remote keyless entry system. Refer to
“Remote keyless entry system” F2-7.
To close the trunk lid, lightly press the
trunk lid down until the latch engages.

NOTE

Do not leave your valuables in the
trunk when you leave your vehicle.

To open the trunk lid from
inside

Pull the trunk lid release lever upward.

Keys and doors/Trunk lid (4–door)

2-23

– CONTINUED –

2-24

Keys and doors/Trunk lid (4–door)

To lock and unlock the trunk
lid release lever

When you entrust your vehicle key to
another person, you can lock the trunk lid
release lever to prevent luggage in the
trunk from being stolen. To lock the trunk
lid release lever, insert the master key or
submaster key into the key cylinder at the
rear of the release lever and turn it
counterclockwise. Then, entrust the per-
son with the valet key only. To unlock the
trunk lid release lever, turn the key clock-
wise.

Internal trunk lid release
handle

The internal trunk lid release handle is a
device designed to open the trunk lid from

inside the trunk. In the event children or
adults become locked inside the trunk, the
handle allows them to open the lid. The
handle is located on the inside of the trunk
lid.

To open the trunk lid from inside the trunk,
pull the yellow handle upward as indicated
by the arrow on the handle.
This operation unlocks the trunk lid. Then,
push up the lid.

The handle is made of material that
remains luminescent for approximately
an hour in the dark trunk space after it is
exposed to ambient light even for a short
time.

WARNING

Never allow any child to get in the
trunk and play with the release
handle. If the driver starts the vehi-
cle without knowing that a child is
inside the trunk and the child opens
the lid using the release handle, the
child could fall out and be killed or
seriously injured.

CAUTION

. Do not close the lid while grip-

ping the release handle. The
handle may be damaged.

. Do not use the handle as a hook

to fasten straps or ropes to
secure your cargo in the trunk.
Such use may result in damage
of the handle.

. Load the trunk so that cargo can

not strike the release handle. If
the cargo hits the handle while
the vehicle is being driven, the
handle may be pulled up and the
trunk lid may open. That may
cause cargo to fall out of the
trunk, which could create a traffic
safety hazard.

Inspection

Perform the following steps at least twice
a year to check the release handle for
correct operation.
1. Open the trunk lid.

2. Use a flat-head screwdriver with a thin
blade. Slide the screwdriver blade from
the slit aperture of the lock assembly to
the end until you hear a click.

This places the latch in the locked posi-
tion.

3. Move the release handle, from outside
the vehicle, in the direction of the arrow to
check if the latch is released.

If the latch is not released, contact your
SUBARU dealer.
In that case, use the key to release the
latch, then close the trunk lid.
Also, if the movement of the release
handle feels restricted or not entirely
smooth during operation, or the handle
and/or handle base is cracked, contact
your SUBARU dealer.

Keys and doors/Trunk lid (4–door)

2-25

2-26

Keys and doors/Rear gate (5–door)

Rear gate (5-door)

The rear gate can be locked and unlocked
using any of the following systems.
. Power door locking switch: Refer to
“Power door locking switches” F2-6.
. Remote keyless entry system: Refer to
“Remote keyless entry system” F2-7.

To open:
First unlock the rear gate lock then push
the rear gate opener button.

To close:
Lower the rear gate slowly and push down
firmly until the latch engages.
The rear gate can be lowered easily if you
pull it down holding the recessed grip.

WARNING

. To prevent dangerous exhaust

gas from entering the vehicle,
always keep the rear gate closed
while driving.

. Do not attempt to shut the rear

gate while holding the recessed
grip. Also avoid closing the rear
gate by pulling on the recessed
grip from inside the cargo space.
There is a danger of your hand
being caught and injured.

CAUTION

. Do not jam a plastic bag in or

place cellophane tape on the rear
gate stays or scratch the stays
while loading or unloading cargo.
That could cause leakage of gas
from the stays, which may result
in their inability to hold the rear
gate open.

. Be careful not to hit your head or

face on the rear gate when open-
ing or closing the rear gate and
when loading or unloading car-
go.

NOTE

If the rear gate cannot be unlocked due
to a discharged vehicle battery, a
malfunction in the door locking/unlock-
ing system or other causes, you can
unlock it by instructionly operating the
rear gate lock release lever. For the
procedure, refer to “Rear gate – if the
rear gate cannot be unlocked” F9-16.

Moonroof (if equipped)

WARNING

Never let anyone’s hands, arms,
head or any objects protrude from
the moonroof. A person could be
seriously injured if any of the follow-
ing conditions occur.

. The vehicle stops suddenly.
. The vehicle turns sharply.
. The vehicle is involved in an

accident.

. Body parts protruding from the

vehicle are struck by outside
objects.

To avoid serious personal injury
caused by accidental or improper
operation, the driver is responsible
for obeying the following instruc-
tions without exception.

. Before closing the moonroof,

make sure that no one’s hands,
arms, head or other objects will
be accidentally caught in the
moonroof.

. Before leaving the vehicle, al-

ways remove the key from the
ignition switch for safety and

never allow an unattended child
to remain in the vehicle. Failure
to follow this procedure could
result in injury to a child operat-
ing the moonroof.

. Never try to check the anti-en-

trapment function by deliberately
placing part of your body in the
moonroof.

CAUTION

. Do not sit on the edge of the open

moonroof.

. Do not operate the moonroof if

falling snow or extremely cold
conditions have caused it to
freeze shut.

. The anti-entrapment function

does not operate when the moon-
roof is being tilted down. Be sure
to confirm that it is safe to do so
before tilting the moonroof down.

The moonroof has both tilting and sliding
functions.

The moonroof operates only when the
ignition switch is in the “ON” position.

Keys and doors/Moonroof

2-27

– CONTINUED –

Subaru Impreza WRX (2014 year). Instruction - part 7
