Subaru Forester (2019). Instruction - part 36





(300,1)

&

Starting engine

!

General precautions when starting
engine

WARNING

.

Never start the engine from out-

side the vehicle (except when
using the remote engine start
system). It may result in an acci-
dent.

.

Do not leave the engine running

in locations with poor ventilation,
such as a garage and indoors.
The exhaust gas may enter the
vehicle or indoors, and it may
result in carbon monoxide poi-
soning.

.

Do not start the engine near dry

foliage, paper, or other flammable
substances. The exhaust pipe
and exhaust emissions can cre-
ate a fire hazard at high tempera-
tures.

CAUTION

.

If the engine is stopped while

driving, the catalyst may over-
heat and burn.

.

When starting the engine, be sure

to sit in the driver’s seat (except
when using the remote engine
start system).

NOTE

.

Avoid rapid racing and rapid accel-

eration immediately after the engine
has started.
.

For a short time after the engine has

started, the engine speed is kept high.
When the warm-up is completed, the
engine speed lowers automatically.
.

On rare occasions, it may be difficult

to start the engine depending on the
fuel and the usage condition (repeated
driving of a distance in which the
engine has not warmed up sufficiently).
In such a case, it is recommended that
you change to a different brand of fuel.
.

On rare occasions, transient knock-

ing may be heard from the engine when
the accelerator is operated rapidly such
as a rapid start-up and a rapid accel-
eration. This is not a malfunction.
.

The engine starts more easily when

the headlights, air conditioner and rear
window defogger are turned off.
.

Do not shift the select lever while the

starter is cranking.

1. Apply the parking brake.

2. Turn off unnecessary lights and acces-
sories.
3. Shift the select lever to the “P” or “N”
position (preferably the “P” position).
The starter motor will only operate when
the select lever is at the “P” or “N” position.
4. Turn the ignition switch to the “ON”
position and check the operation of the
warning and indicator lights. Refer to
“Warning and indicator” FP164.
5. Turn the ignition switch to the “START”
position without depressing the accelera-
tor pedal. Release the key immediately
after the engine has started.

If the engine does not start, try the
following procedure.

(1) Turn the ignition switch to the
“LOCK”/“OFF” position and wait for at
least 10 seconds. After checking that
the parking brake is firmly set, turn the
ignition switch to the “START” position
while depressing the accelerator pedal
slightly (approximately a quarter of the
full stroke). Release the accelerator
pedal as soon as the engine starts.
(2) If this fails to start the engine, turn
the ignition switch back to the “LOCK”/
“OFF” position and wait for at least 10
seconds. Then fully depress the accel-
erator pedal and turn the ignition
switch to the “START” position. If the

Starting and stopping the engine (models without push-button start system)

298

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(301,1)

engine starts, quickly release the ac-
celerator pedal.
(3) If this fails to start the engine, turn
the ignition switch again to the “LOCK”/
“OFF” position. After waiting for 10
seconds or longer, turn the ignition
switch to the “START” position without
depressing the accelerator pedal.
(4) If the engine still does not start,
contact your nearest SUBARU dealer
for assistance.

6. Confirm that all warning and indicator
lights have turned off after the engine has
started. The fuel injection system auto-
matically lowers the idle speed as the
engine warms up.

While the engine is warming up, make sure
that the select lever is in the “P” or “N”
position and that the parking brake is
applied.

CAUTION

If you restart the engine while the
vehicle is moving, shift the select
lever into the “N” position. Do not
attempt to place the select lever of a
moving vehicle into the “P” position.

&

Stopping the engine

The ignition switch should be turned off
only when the vehicle is stopped and the
engine is idling.

WARNING

Do not stop the engine when the
vehicle is moving. This will cause
loss of power to the power steering
and the brake booster, making steer-
ing and braking more difficult. It
could also result in accidental acti-
vation of the “LOCK”/“OFF” posi-
tion on the ignition switch, causing
the steering wheel to lock.

7-5. Starting and stopping
engine (models with push-
button start system)

&

Safety precautions

Refer to “Safety precautions” FP111.

&

Operating range for push-
button start system

Refer to “Operating range for push-button
start system” FP158.

&

Starting engine

WARNING

.

There are some general precau-

tions when starting the engine.
Carefully read the precautions
described in “Starting engine”
FP298.

.

If the indicator on the push-but-

ton ignition switch flashes in
green after the engine has
started, never drive the vehicle.
The steering is still locked, and it
may result in an accident.

– CONTINUED –

Starting and stopping engine (models with push-button start system)

299

7

Starting

and

operating

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(302,1)

CAUTION

.

When the operation indicator on

the push-button ignition switch is
flashing in orange, there may be a
malfunction with the vehicle.
Contact a SUBARU dealer imme-
diately.

.

If the indicator on the push-but-

ton ignition switch is flashing in
green after the engine has
started, it means that the steering
is still locked. Depress the brake
pedal while moving the steering
wheel to the right and left, and
press the push-button ignition
switch.

.

Do not continue pushing the

push-button ignition switch for
more than 10 seconds. Doing so
could cause a malfunction. If the
engine does not start, stop push-
ing the push-button ignition
switch. Instead, press the push-
button ignition switch without
depressing the brake pedal to
switch the power status to
“OFF”. Wait 10 seconds, and then
push the push-button ignition
switch to start the engine.

NOTE

.

For a short time after the engine has

started, the engine speed is kept high.
When the warm-up is completed, the
engine speed lowers automatically.
.

When the push-button ignition

switch is pressed while depressing
the brake pedal, the engine starter
operates for a maximum of 10 seconds.
After starting the engine, the starter
stops automatically.
.

When the push-button ignition

switch is pressed while depressing
the brake pedal, the engine can be
started regardless of the status of the
push-button ignition switch.
.

If the security indicator light illumi-

nates when you attempt to start the
engine but the engine does not start,
press the push-button ignition switch
to switch the power to “OFF” and then
try to start the engine again.
.

If the engine does not start, press the

push-button ignition switch without
depressing the brake pedal to switch
the power to “OFF”. Then, while de-
pressing the brake pedal more force-
fully, press the push-button ignition
switch.
.

The engine start procedures may not

function depending on the radio wave
conditions around the vehicle. In such

a case, refer to “Starting engine”
FP428.
.

If the vehicle battery is discharged,

the steering cannot be unlocked.
Charge the battery.
.

Do not shift the select lever while the

starter is cranking.

1)

Operation indicator

2)

Push-button ignition switch

When the push-button ignition switch is
pressed while depressing the brake pedal,
the engine will start. The starting proce-
dure for the engine is as follows.

Starting and stopping engine (models with push-button start system)

300

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(303,1)

1. Carry the access key fob, and sit in the
driver’s seat.
2. Apply the parking brake.
3. Shift the select lever into the “P”
position. The engine can also start when
the select lever is in the “N” position,
however, for safety reasons, start in the “P”
position.
4. Depress the brake pedal until the
operation indicator on the push-button
ignition switch turns green. When starting
with the select lever in the “N” position, the
indicator does not turn green.
5. While depressing the brake pedal,
press the push-button ignition switch.

NOTE

.

While pressing the select lever but-

ton in, the indicator on the push-button
ignition switch will not turn green even
when the select lever is in the “P”
position.
.

In case the engine does not start by

the normal engine start procedure,
move the select lever to the “P” posi-
tion, and switch the power to “ACC”.
Depress the brake pedal, and press the
push-button ignition switch for at least
15 seconds. The engine may start. Only
use this engine start procedure in case
of emergency.

.

When the engine is not started, the

brake pedal may feel stiff. In such a
case, depress the brake pedal more
forcefully than usual. Check that the
operation indicator on the push-button
ignition switch turns green, and press
the push-button ignition switch to start
the engine.

&

Stopping engine

1. Stop the vehicle completely.
2. Move the select lever to the “P”
position.
3. Press the push-button ignition switch.
The engine will stop, and the power will be
switched off.

WARNING

.

Do not touch the push-button

ignition switch during driving.

When the push-button ignition
switch is operated as follows,
the engine will stop.

– The switch is pressed and held

for 3 seconds or longer.

– The switch is pressed briefly 3

times or more in succession.

When the engine stops, the brake
booster will not function. A great-

er foot pressure will be required
on the brake pedal.

The power steering system will
not operate either. A greater force
will be required to steer, and it
may result in an accident.

.

If the engine stops during driving,

do not operate the push-button
ignition switch or open any of the
doors until the vehicle is stopped
in a safe location. It is dangerous
because the steering lock may be
activated. Stop the vehicle in a
s a f e p l a c e , a n d c o n t a c t a
SUBARU dealer immediately.

CAUTION

.

Do not stop the engine while the

select lever is in a position other
than the “P” position.

.

If the engine is stopped while the

select lever is in a position other
than the “P” position, the power
will be in “ACC”. If the vehicle is
left in this condition, the battery
may be discharged.

– CONTINUED –

Starting and stopping engine (models with push-button start system)

301

7

Starting

and

operating

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(304,1)

NOTE

Although you can stop the engine by
operating the push-button ignition
switch, do not stop the engine during
driving except in an emergency.

&

When access key fob does
not operate properly

Refer to “Access key fob – if access key
fob does not operate properly” FP427.

7-6. Remote engine start
system (dealer option)

WARNING

.

There are some general precau-

tions when starting the engine.
Carefully read the precautions
described in “General precau-
tions when starting engine”
FP298.

.

Do not remote start a vehicle in an

enclosed environment (e.g.
closed garage). Prolonged opera-
tion of a motor vehicle in an
enclosed environment can cause
a harmful build-up of carbon
monoxide. Carbon monoxide is
harmful to your health. Exposure
to high levels of carbon monox-
ide can cause headaches, dizzi-
ness or in extreme cases uncon-
sciousness and/or death.

The remote engine start system allows you
to start the engine from outside the vehicle.
In addition, the remote engine start system
can activate the heater or air conditioner,
providing you with a comfortable cabin
upon entry. For more details, refer to the
Owner’s Instruction supplement for the re-

mote engine start system.

NOTE

.

The length of time for which it is

acceptable to allow the engine to
remain idling may be bound by local
laws and regulations. Check the local
rules when using the remote engine
start system.
.

When taking your vehicle in for

service, it is recommended that you
inform the service personnel that your
vehicle is equipped with a remote
engine start system.

&

Remote engine starter trans-
ceiver (fob)

1)

Fob button

Remote engine start system (dealer option)

302

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(305,1)

!

Starting the engine

NOTE

All vehicle doors (including rear gate)
and the engine hood must be closed
prior to activating the remote engine
start system. Any open entry point will
prevent starting or cause the engine to
stop.

The remote engine start system is acti-
vated by pressing the fob button on your
remote engine starter transceiver (fob)
twice within 3 seconds. If the fob is within
operating range of the system and the start
request is received, the following will
occur.
.

The fob flashes and beeps once.

.

The horn sounds once.

.

The side marker lights, tail lights, and

parking lights flash once.

If the fob is not within range (the user is too
far away from the vehicle), the fob will
indicate two long flashes without beeping.

The system will check certain safety
preconditions before starting, and if all
conditions are met, the engine will start
within 5 seconds. After the engine starts,
the following will occur.
.

The fob flashes and beeps twice.

.

The horn sounds once.

.

The side marker lights, tail lights, and

parking lights flash once.

While the engine is idling via the remote
engine start system, the following will
occur.
.

The side marker lights, tail lights, and

parking lights remain illuminated.
.

The fob button flashes once every 3

seconds.
.

The power windows are disabled.

If the engine turns over but does not start
(or starts and stalls) the remote engine
start system will power off and then
attempt to start the engine 3 additional
times. The system will not attempt to
restart the engine if it determines a vehicle
malfunction is preventing starting. If the
engine does not start after 3 additional
attempts, the remote engine start request
will be aborted.

!

Stopping the engine

Press and hold the fob button for at least 2
seconds to stop the engine. The fob will
flash and beep three times, indicating the
engine has stopped. If the stop request is
not received (for example, if the user is too
far away from the vehicle), the fob will
continue to flash once every 3 seconds.
The system will automatically stop the
engine after 15 minutes.

!

Remote start safety features

For safety and security reasons, the
remote engine start system will prevent
starting (or stop the engine if running) and
sound the horn twice if any of the following
conditions is detected. In addition, the fob
will flash and beep 3 times.
.

The total run-time has exceeded 20

minutes.
.

The brake pedal is depressed.

.

A key is in the ignition switch.

.

The engine hood is open.

.

The engine idle speed exceeds 3,500

rpm.
.

The security alarm is triggered.

.

The select lever is not in the “P”

position.

If the system detects any door (including
the rear gate) open during operation, it will
prevent starting or stop the engine, and
sound the horn and flash side marker
lights, tail lights, and parking lights 6 times.

In addition to the items above, if the
vehicle’s engine management system
determines there is a safety risk due to a
vehicle-related problem, the vehicle will
power down and the horn will sound 3
times.

– CONTINUED –

Remote engine start system (dealer option)

303

7

Starting

and

operating

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(306,1)

NOTE

.

If the alarm system is armed at the

time of remote engine starter activation
(the security indicator light on the
combination meter is flashing), the
alarm system will remain armed
throughout the remote start run cycle.
.

If the alarm system is disarmed at

the time of remote engine starter acti-
vation (the security indicator light on
the combination meter is not flashing),
the alarm system will remain disarmed
throughout the remote start run cycle.

!

Remote start operation - fob con-
firmation

Your remote engine starter fob is a
bidirectional transceiver that can confirm
system operation with several different
visual and audible indications. The fob’s
LED-backlit button and internal piezo
buzzer will indicate status of the system
using the following flash and beep se-
quences, provided the fob is within opera-
tional range of the system.

Remote engine start system (dealer option)

304

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(307,1)

Precondition

Fob Indication

Meaning

Flash

Beep

Fob start button is being pressed

Continuous while button is
held down

The fob is transmitting an RF signal

User attempts to start engine by pressing fob
button twice within 3 sec

1 flash

1 beep

Engine start request received

2 flashes

2 beeps

Engine started successfully

1 flash every 3 sec

Engine idling

3 flashes

3 beeps

Vehicle is in range but engine not started

2 long flashes

Vehicle not in range (engine not started)

Engine idling by remote engine start operation

1 flash every 3 sec

Engine idling

3 flashes

3 beeps

Engine stopped by system timeout or for safety
reasons (see sections above)

User attempts to stop engine by pressing and
holding fob button for at least 2 sec.

3 flashes

3 beeps

Engine stopped by user request

1 flash every 3 sec

Stop request not received. Engine still idling.

– CONTINUED –

Remote engine start system (dealer option)

305

7

Starting

and

operating

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content   ..  34  35  36  37   ..
